Siemens SIRIUS Motor Protection Unit 24V DC Thermistor SIMOCODE Pro C System 4 Poles 3UF7000-1AB00-0
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Siemens |
| Model | 3UF7000-1AB00-0 |
| IP Rating | IP20 |
| Overall Length | 111mm |
| Series | SIRIUS |
| Overall Width | 45mm |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -25°C |
| Sensing type | Thermistor |
| Supply Voltage | 24V dc |
| Number of Poles | 4 |
| Standards/Approvals | CSA |
| Overall Depth | 95mm |
| Motor Protection Component | Basic Unit |
| Motor Protection System | SIMOCODE Pro C |
Key Features
- Provides multifunctional solid-state motor protection independent of automation system.
- Supports flexible control with software-based motor management.
- Includes 4 binary inputs and 3 monostable relay outputs with thermistor connection.
- Operates within temperature range -25°C to 60°C with IP20 protection.
- Equipped with PROFIBUS DP communication for open system integration.
- Compact design suitable for standard rail or mounting plate installations.
- CSA approved and manufactured in Germany for high quality standards.
Product Description
Siemens 3UF7000-1AB00-0 Motor Protection Unit is an advanced basic unit designed for comprehensive motor management within the SIMOCODE Pro C series and SIRIUS product line. Operating at 24V DC power supply and featuring thermistor sensing, this unit offers solid-state full motor protection independent of higher-level automation systems.
Designed to optimize the connection between control and motor systems, it facilitates increased plant availability and cost savings throughout startup, operation, and maintenance phases in industrial automation, manufacturing, and process control applications.
This unit’s flexible software-based control allows integration of detailed operational, service, and diagnostic data to enhance system performance. Communication is enabled via PROFIBUS DP, the fieldbus standard for industrial data exchange.
The motor protection unit supports direct-on-line and reversing starters, actuating circuit-breakers with up to 4 binary inputs and 3 relay outputs. It includes a thermistor input for binary PTC monitoring. Compact in size with dimensions of 111 mm length, 45 mm width, and 95 mm depth, it fits standard rail mountings or mounting plates via push-in lugs.
Operating temperature range is from -25°C to 60°C with an IP20 ingress protection rating, ensuring robust performance in typical industrial environments. The product holds CSA certification and is manufactured in Germany, guaranteeing quality and compliance with international standards.
Multifunctional solid-state motor protection independent of automation system. Flexible software motor control and detailed diagnostics data. Four binary inputs, three monostable relay outputs, and thermistor connection.
Open communication through PROFIBUS DP fieldbus standard. Compact design with mounting flexibility. Suitable for direct-on-line and reversing starter applications. IP20 rated with operating temperature from -25°C to 60°C.
CSA approved product made in Germany.
This Siemens Motor Protection Unit is ideal for industrial automation, manufacturing plants, HVAC systems, and electrical motor protection applications. Explore more Siemens motor products and accessories on EnvMart for reliable performance and technical support.
Explore more products in our Motor Protection Units category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Siemens SIRIUS Motor Protection Unit operates within a temperature range of -25°C to 60°C.
It uses thermistor sensing for motor protection.
The supply voltage for this motor protection unit is 24V DC.
This model has 4 poles.
The dimensions are 111 mm in length, 45 mm in width, and 95 mm in depth.
It has an IP20 ingress protection rating.
It supports PROFIBUS DP communication for open system integration.
This unit is CSA approved, ensuring compliance with international standards.
It supports direct-on-line and reversing starters.
It includes 3 monostable relay outputs and 4 binary inputs.
It is manufactured in Germany, ensuring high quality standards.
It is suitable for industrial automation, manufacturing plants, HVAC systems, and electrical motor protection applications.
