Celduc SO8 Series Solid State Relay, 95 A Load, DIN Rail Mount, 510 Vrms Load, 32V Control SO868070

Celduc SO868070 is a high-performance solid state relay from the SO8 series designed for electrical and industrial control applications. It supports a maximum load current of 95 A and a maximum load voltage of 510 Vrms, making it suitable for single-phase AC load switching in industrial automation and other heavy-duty electrical installations. This relay features zero cross switching to reduce electrical noise and provide smooth operation of resistive and inductive loads.

The device offers a wide input control voltage range from 3.5 V dc to 32 V dc, regulated by a control current to ensure precise switching. The relay comes with screw terminal connections configured as a single-pole single-throw (SPST) contact. It is designed for mounting on standard DIN rails, providing ease of integration into electrical panels.

Constructed to withstand harsh environments, the SO868070 operates reliably over a temperature range of -40°C to 100°C. It includes protection components such as transils for input voltage and VDRs for output suppression, enhancing immunity against electrical interference.

The relay is compact with dimensions 58.5 mm long, 44.8 mm wide, and 30 mm high, making it well-suited for dense panel configurations. It has an IP20 rating for protection against solid object ingress, suitable for controlled industrial environments.

Single-phase solid state relay with 95 A load current capacity. Zero cross switching reduces electrical noise and improves load control. Wide input control voltage range from 3.5 to 32 V dc with regulated control current.

Screw terminal connection with SPST contact configuration. Robust operation from -40°C to 100°C ambient temperature. Compact size ideal for DIN rail mounting in industrial panels. On-state resistance of 16 milliohms minimizes conduction losses.

Low off-state leakage current of 1 mA. Complies with multiple international approvals including CE, CSA, UKCA, and RoHS.

This solid state relay is ideal for applications across industrial automation, manufacturing process control, electrical machinery protection, HVAC systems, and commercial electrical installations requiring reliable, noise-free switching. The France-manufactured product ensures high build quality and compliance with stringent safety and interference immunity standards.
