United Automation 1-Channel Linear Voltage Regulator, Adjustable Output 6A, 230V 60Hz CSR604B
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | United Automation |
| Height | 35.7mm |
| Length | 17.5mm |
| Model | CSR604B |
| Width | 7.6mm |
| Mount Type | Through Hole |
| Output type | Adjustable |
| Series | CSR604 |
| Output Current | 6A |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | 0°C |
| Regulator Type | Linear Voltage |
| Switching Frequency | 60Hz |
| Number of outputs | 1 |
| Maximum Input Voltage | 230V |
| Output Voltage | 230V |
| Minimum Input Voltage | 110V |
| Pin Count | 3 |
Key Features
- Designed for controlling single phase mains driven loads up to 6A.
- Operates with an input voltage range from 110V to 230V AC.
- Through hole mounting type with 3-pin configuration ensures ease of installation.
- Suitable for resistive heating elements such as quartz lamps, ovens, moulders, and dryers.
- Also compatible with inductive loads including transformers, fans, and motors.
- Features a transistor style housing with an isolated heat sink tab for thermal management.
- Compact dimensions with length 17.5mm, width 7.6mm and height 35.7mm.
- Ambient operating temperature range from 0°C to 70°C for reliable performance.
Product Description
United Automation CSR604B 1-Channel Linear Voltage Regulator is a solid-state power regulator designed to control single-phase mains loads with a capacity of up to 6 amperes at 230 volts and 60 Hz.
This linear Voltage Regulator operates via a 3-pin through-hole mounting configuration and provides adjustable output voltage for precise control over power delivery.
Its compact transistor-style housing includes an isolated heat sink tab, aiding in thermal dissipation during operation. The device dimensions are 17.5 mm in length, 7.6 mm in width, and 35.7 mm in height, making it suitable for installation in applications with limited space.
The CSR604B is compatible with conventional resistive heating elements such as quartz lamps, ovens, moulders, and dryers. Additionally, it supports certain inductive loads including transformers, fans, and motors, extending its versatility in industrial and commercial equipment.
Designed to operate reliably between 0°C and 70°C ambient temperature, this regulator requires external 220 kΩ or 250 kΩ linear potentiometers (not included) to adjust power output from 0% to 98%.
Controls single phase mains-driven loads up to 6A. Input voltage range is from 110V to 230V AC at 60 Hz frequency. Through hole mounting with three pins ensures secure installation. Suitable for resistive and certain inductive loads.
Transistor style housing with isolated heat sink tab enhances heat dissipation. Compact size with length 17.5mm, width 7.6mm, height 35.7mm. Operating temperature range 0°C to 70°C for robust use in different environments.
Adjustable output voltage enables precise power regulation. This power management IC is ideal for use in industrial automation systems, electronics manufacturing, and HVAC equipment requiring reliable and adjustable voltage regulation.
Discover more products within the Power Management ICs category on EnvMart for your automation and control needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output current of this model is 6A.
This unit operates with an input voltage range from 110V to 230V AC.
The dimensions of this model are 17.5 mm in length, 7.6 mm in width, and 35.7 mm in height.
The ambient operating temperature range is from 0°C to 70°C.
It features a through-hole mounting type with a 3-pin configuration for secure installation.
The output type is adjustable, allowing for precise control over power delivery.
The CSR604B operates at a switching frequency of 60Hz.
The country of origin for this voltage regulator is the United Kingdom.
This voltage regulator has one output channel.
It is a linear voltage regulator designed for controlling single-phase mains loads.
