Legrand Linear DIN Rail Power Supply 400V AC Input 24V DC, 2.5A Output DC 60W 0 470 22

Free Delivery in India | Lowest Global Shipping Charges

Legrand Linear DIN Rail Power Supply 400V AC Input 24V DC, 2.5A Output DC 60W 0 470 22

Name: Legrand Linear DIN Rail Power Supply 400V AC Input 24V DC, 2.5A Output DC 60W 0 470 22
Brand: Legrand
SKU: 189262



Category DIN Rail Power Supplies Brand Legrand Condition New

Specifications

Country of Origin	France
Brand	Legrand
Power	60W
Height	93mm
Model	0 470 22
Depth	105mm
Width	93mm
Output Current	2.5A
Maximum Operating Temperature	60°C
Sub Type	Linear
Minimum Operating Temperature	-10°C
Number of outputs	2
Maximum Input Voltage	400V ac
Electrical Phase	1
Maximum Output Voltage	24V dc
Minimum Input Voltage	230V ac

Key Features

Input voltage range from 230V AC to 400V AC ensures wide compatibility.
Single-phase electrical phase with two output terminals for easy connection.
Linear power supply design with integral output protection fuse.
Operating temperature range between -10°C and 60°C suitable for industrial environments.
Equipped with green LED status indicator for operational monitoring.
Compact dimensions of 93mm width, 93mm height, and 105mm depth for DIN rail mounting.
Low ripple factor and noise less than 3% for clean DC output.
Manufactured in France with high quality standards.

Product Description

Legrand 0 470 22 Linear DIN Rail Power Supply is designed for industrial and commercial applications requiring a stable DC power source. It provides a 24V DC output with a current of 2.5A and a power rating of 60W. The single-phase input accepts voltages from 230V AC to 400V AC, ensuring compatibility with a range of electrical systems.

This power supply features a linear design with a safety transformer that incorporates interference filtering and capacitors, delivering reliable and noise-reduced output. An integral output fuse protects the unit from overload conditions, while the green LED status indicator provides visual confirmation of operational status.

The product has a compact footprint with dimensions of 93mm in width, 93mm in height, and 105mm in depth, making it well-suited for DIN rail mounting in electrical panels. It operates safely over a temperature range from -10°C to 60°C, suitable for harsh industrial environments.

Legrand DIN Rail Power Supply includes twin output terminals for ease of wiring and an insulated coupling bar that allows quick and safe earth terminal connections up to 15A. The ripple factor and noise are kept below 3%, ensuring clean output power for sensitive electronics.

Manufactured in France, this power supply adheres to high quality and safety standards, though no specific certifications are listed. It is commonly used in industrial, laboratory, commercial, HVAC, and manufacturing applications where a stable and isolated DC power supply is needed.

Input voltage range 230V AC to 400V AC. Output voltage 24V DC at 2.5A current. Power capacity of 60W. Operating temperature from -10°C to 60°C. Compact dimensions for DIN rail mounting. Green LED for status indication. Integral output protection fused feature.

Low noise and ripple below 3%. Safety transformer with interference filtering. Twin output terminals for simplified connection. Explore more Legrand power supplies and electronic components in EnvMart’s comprehensive catalog.
