WEG Motor Control Contactor 4-Pole 9A 4.5kW 230V AC Coil CWC09-00-22D24

Free Delivery in India | Lowest Global Shipping Charges

WEG Motor Control Contactor 4-Pole 9A 4.5kW 230V AC Coil CWC09-00-22D24



Category Contactors Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC09-00-22D24
Depth	52mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	4.5kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	4
Standards/Approvals	IEC, RoHS, UL
Contact Voltage	690V ac
Coil Voltage	230V ac
Normal State Configuration	2 NO/2 NC
Contact Current	9A
Auxiliary Contact Configuration	2 NO/2 NC
Operational Current Ie	9A
Control Circuit Voltage Uc	230V ac
Contactor Application	Motor Control
Pole and Throw Configuration	4PST

Key Features

Equipped with a coil voltage rating of 230V AC for reliable operation.
4-pole design suitable for motor control applications.
Contact current rated at 9 amperes for moderate power loads.
Includes 2 normally open and 2 normally closed auxiliary contacts for versatile switching.
Compact dimensions measuring 58mm length, 45mm width, and 52mm depth for space-saving installation.
Mounting via DIN Rail ensures secure and standardized attachment.
Terminal connection type is screw for secure and easy wiring.
Operational temperature range from -25°C to 55°C suitable for varied environments.

Product Description

WEG CWC09-00-22D24 is a professional-grade motor control contactor designed for switching electric motors efficiently. This contactor features a robust 230V AC coil and a 4-pole configuration, supporting a contact current of 9 amperes and a power rating of 4.5 kW at 230V AC. It is built to meet IEC/EN60947 and DIN VDE 0660 standards ensuring reliability and safety in industrial applications.

The compact and modular design with dimensions of 58mm length, 45mm width, and 52mm depth provides space-saving installation options. The product mounts easily on DIN rail panels and uses screw terminal connections for secure wiring. It incorporates 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts, offering versatile control options.

This contactor functions reliably within an ambient temperature range of -25°C to 55°C and is suitable for various industrial, automation, HVAC, and electrical motor switching applications.

Coil voltage rating of 230V AC for efficient actuation. 4 poles for comprehensive motor control configurations. Contact current rating of 9A supporting moderate load operations. Includes 2 NO and 2 NC auxiliary contacts enhancing control flexibility.

DIN rail mount for standard industrial panel integration. Compliant with IEC, RoHS, and UL for international usage. Screw terminal type for reliable electrical connections. Compact size ensures ease of installation in constrained spaces.

Operational temperature from -25°C to 55°C for diverse environments. Manufactured in Brazil, assuring global quality benchmarks.

This contactor is an ideal solution for industrial, manufacturing, HVAC, and commercial electrical automation tasks requiring reliable motor control. Browse EnvMart’s extensive Automation & Control Gear category for compatible control devices and accessories suitable for your applications.
