WEG CWC Series Contactor, 110V AC Coil, 3-Pole, 22A, 11 kW Power Rating, DIN Rail Mount CWC025-00-30D13



Category Contactors Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC025-00-30D13
Depth	56mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	11kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	IEC, RoHS, UL
Contact Voltage	690V ac
Coil Voltage	110V ac
Normal State Configuration	3 NO
Contact Current	22A
Operational Current Ie	25A
Control Circuit Voltage Uc	110V ac
Contactor Application	Motor Control
Pole and Throw Configuration	3PST

Key Features

Equipped with a 110V AC coil for reliable actuation.
Three-pole configuration suitable for three-phase motor control.
Rated current of 22 amperes with 11 kW power rating for efficient switching.
Compact, modular design with DIN rail mounting for easy installation.
Designed and tested according to IEC/EN60947 and DIN VDE 0660 standards.
Features screw terminals for secure electrical connections.
Integrated 3 NO (Normally Open) auxiliary contacts for control circuits.
Operates effectively between -25°C to 55°C ambient temperature range.

Product Description

WEG CWC025-00-30D13 Contactor features a robust industrial-grade design with 110V AC coil suitable for motor control applications requiring precise switching. This three-pole contactor is rated for 22A contact current and an 11 kW power rating at 690V AC contact voltage, ensuring efficient operation in demanding electrical environments.

The CWC Series is known for its compact, modular form factor optimized for DIN rail mounting and panel installations, saving valuable space while providing high reliability. Its screw-type terminals facilitate secure electrical connections during installation and maintenance.

Manufactured to comply with IEC/EN60947 and DIN VDE 0660 standards, this contactor offers proven durability and compliance with global electrical safety standards. Its operational temperature range from -25°C to 55°C allows versatility across industrial conditions.

The contactor includes three normally open (3 NO) auxiliary contacts which support complex control circuit configurations in automation and motor control systems. It is ideal for use in industrial automation, manufacturing plants, HVAC control panels, and other commercial electrical systems requiring reliable motor control functionality.

Key technical specifications include a coil voltage of 110V AC, contact voltage of 690V AC, operational current of 25A, and dimensions of 56 mm depth, 58 mm length, and 45 mm width. The product is a professional-grade solution from WEG, developed in Brazil, emphasizing quality and performance.

Equipped with 110V AC coil for precise motor control. Three-pole design supports three-phase applications. Rated for 22A contact current and 11 kW power switching. Compact design with DIN rail mounting compatibility. Complies with IEC/EN60947 and DIN VDE 0660 standards.

Screw terminals ensure secure electrical connections. Includes 3 NO auxiliary contacts for control flexibility. Functional across a wide temperature range of -25°C to 55°C. Manufactured in Brazil with high quality standards.
