BK Precision Digital Bench Power Supply, 1-Output 300 V to 300 V, 1.5 kVA, 12 A Max BK9805

Free Delivery in India | Lowest Global Shipping Charges

BK Precision Digital Bench Power Supply, 1-Output 300 V to 300 V, 1.5 kVA, 12 A Max BK9805

Name: BK Precision Digital Bench Power Supply, 1-Output 300 V to 300 V, 1.5 kVA, 12 A Max BK9805
Brand: BK Precision
SKU: 187424
Price: 20.22 USD
Availability: InStock



Category Bench Power Supplies Brand BK Precision Condition New

Specifications

Country of Origin	China
Brand	BK Precision
Model	BK9805
Output type	0/300 V
Maximum Operating Temperature	40°C
Minimum Operating Temperature	0°C
Plug Type	Universal
Interfaces	Standard USB (USBTMC-compliant), RS232, LAN and GPIB interfaces
Number of outputs	1
Maximum Output Current	12A
Maximum Output Voltage	300V
Maximum Supply Voltage	220V ac
Minimum Supply Voltage	110V ac
Digital/Analogue	Digital

Key Features

Adjustable output voltage from 0 to 300 V with 0.1 V resolution.
Output frequency adjustable from 45 Hz to 500 Hz with phase angle control.
Built-in power line disturbance simulation for grid fault testing.
Digital VFD display shows voltage, current, frequency, and power parameters.
Multiple interfaces including USB, RS232, LAN, and GPIB for remote control.
Selectable autoranging between 150 V and 300 V for continuous sweep.
Compliant with IEC61000-4-11, 4-14, and 4-28 pre-compliance standards.
Includes power cord, rackmount ears, handles, manual, test report, and calibration certificate.

Product Description

BK Precision BK9805 digital bench power supply is a high-performance programmable AC source ideal for industrial and laboratory applications. Delivering up to 1.5 kVA power and a maximum output current of 12 A, it supports a variable output voltage range from 0 to 300 V with fine 0.1 V resolution. The unit also provides an adjustable output frequency from 45 Hz to 500 Hz and phase angle control between 0 and 360 degrees, allowing thorough simulation of AC characteristics.

This digital bench power supply includes a bright vacuum fluorescent display (VFD) showing critical measurements such as Vrms, Irms, Ipeak, frequency, power factor, apparent power, and true power. It features built-in power line disturbance (PLD) simulation modes including list and sweep to replicate common power grid faults for comprehensive device testing and evaluation.

The BK9805 supports selectable autoranging operation between 150 V and 300 V for continuous voltage sweep. It comes equipped with multiple communication interfaces including standard USB (USBTMC-compliant), RS232, LAN, and GPIB, enabling remote control and monitoring for integration into automated test setups.

Designed for evaluating transformers, TRIACs, SCRs, and passive components, this power supply is well suited for production, research and development, service labs, and pre-compliance testing. It is compliant with voltage dip and frequency simulation standards IEC61000-4-11, IEC61000-4-14, and IEC61000-4-28.

The product is supplied complete with an unterminated power cord with input connector, rackmount ears, handling grips, an instruction manual, a test report, and a certificate of calibration. It is manufactured in China, ensuring quality and reliability for demanding test environments.

Adjustable output voltage from 0 to 300 V with 0.1 V resolution. Built-in power line disturbance and dimmer simulation features. Multiple interfaces for remote control and automation integration. Comprehensive digital readout displaying essential electrical parameters.

Suitable for industrial, laboratory, and compliance testing applications. Supplied with comprehensive accessories and calibration certificate. Explore more Bench Power Supplies and digital test instruments in the Industrial Machines & Instruments category at EnvMart for enhanced testing and measurement solutions.
