Schneider Electric Contactor 24V AC Coil, 4-Pole, 9A Contact Current, 1.56W Power Rating, 690V AC Contact Voltage LC1D098B7
Specifications
| Country of Origin | Indonesia |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 85mm |
| Model | LC1D098B7 |
| Depth | 90mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LC1D |
| Power Rating | 1.56W |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Screw |
| Number of Poles | 4 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 690V ac |
| Coil Voltage | 24V ac |
| Normal State Configuration | 2 NO/2 NC |
| Better World Claim | Designed for Disassembly |
| Contact Current | 9A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 20A |
| Control Circuit Voltage Uc | 24V ac |
| Contactor Application | Resistive Load |
| Pole and Throw Configuration | 4 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Designed for motor control and resistive load applications.
- Equipped with 2 NO and 2 NC normal state contact configuration.
- Includes 2 auxiliary contacts configured as 1 NO and 1 NC.
- DIN Rail mountable with screw terminal type connections offering IP20 finger-safe protection.
- Operational temperature range from -5°C to 60°C suitable for industrial environments.
- Compact dimensions with 85mm length, 45mm width, and 90mm depth.
- Meets international standards including CCC, CSA, EAC, IEC, RoHS, and UL approvals.
- Designed and manufactured in Indonesia with high reliability and resistance to shock and vibration.
Product Description
Schneider Electric LC1D098B7 Contactor is a reliable device engineered for motor control and resistive load applications, operating with a 24V AC coil voltage and rated for contact current of 9A. It supports a 4-pole configuration and has a power rating of 1.56W at 24V AC coil voltage, making it suitable for demanding industrial control circuits.
This contactor features a normal state configuration of 2 normally open and 2 normally closed contacts, complemented by 2 auxiliary contacts with a 1 NO and 1 NC layout, enhancing its control and signaling capabilities. The screw terminal connections provide IP20 finger-safe protection, ensuring safe and secure wiring installation for panel or DIN rail mounting.
Designed with robust mechanical and electrical durability, the contactor can withstand shocks and vibrations common in industrial environments. It complies with multiple international standards including CCC, CSA, EAC, IEC, RoHS, and UL certifications, reflecting its quality and safety.
The operating temperature range of -5°C to 60°C allows usage across diverse climatic conditions. Its compact dimensions of 85mm length, 45mm width, and 90mm depth facilitate easy integration in control panels. Manufactured in Indonesia, this device offers lasting performance in motor starters, resistive loads, and automation control systems.
Additional features include IP20 finger-safe terminals with international and North American markings, flexible control circuit compatibility, and the ability to mount using screws or DIN rail systems. The contactor belongs to the TeSys D series that provides double breaking of poles via linear translation movement.
Designed for motor control and resistive loads. 4-pole contactor with 2 NO and 2 NC contacts. Auxiliary contacts for extended functionality. IP20 screw terminals for safety. Compact design for easy panel mounting. Complies with CCC, CSA, EAC, IEC, RoHS, and UL standards.
Explore more Schneider Electric products in the Contactor category on EnvMart, where you find high-quality industrial electrical components for your engineering and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The power rating of this contactor is 1.56W at a coil voltage of 24V AC.
The maximum contact voltage for the LC1D098B7 is 690V AC.
This contactor features a 4-pole configuration.
It is designed for motor control and resistive load applications.
The operational temperature range is from -5°C to 60°C.
The contact current rating is 9A.
The normal state configuration includes 2 normally open (NO) and 2 normally closed (NC) contacts.
Yes, it includes 2 auxiliary contacts configured as 1 normally open (NO) and 1 normally closed (NC).
It supports DIN rail mounting with screw terminal type connections.
It complies with multiple international standards including CCC, CSA, EAC, IEC, RoHS, and UL.
The dimensions are 85mm in length, 45mm in width, and 90mm in depth.
It features IP20 finger-safe terminals with both North American and International markings.
