Amphenol Limited MIL Spec Circular Connector Brass Straight 14 Way 500V AC 13A Wall Mount Olive Drab 97B-3100A-22-19S

Free Delivery in India | Lowest Global Shipping Charges

Amphenol Limited MIL Spec Circular Connector Brass Straight 14 Way 500V AC 13A Wall Mount Olive Drab 97B-3100A-22-19S

Name: Amphenol Limited MIL Spec Circular Connector Brass Straight 14 Way 500V AC 13A Wall Mount Olive Drab 97B-3100A-22-19S
Brand: Amphenol Limited
SKU: 185794
Price: 58.92 USD
Availability: InStock



Category Mil Spec Circular Connector Brand Amphenol Limited Condition New

Specifications

Country of Origin	India
Voltage	500V ac
Brand	Amphenol Limited
Colour	Olive
Orientation	Straight
Current	13A
Model	97B-3100A-22-19S
Mount Type	Wall Mount
Housing Material	Aluminium Alloy
Contact Material	Brass
Series	97B
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Contact Plating	Silver
Number of Contacts	14
Contact Gender	Female
Connector Gender	Female
Shell Size	22
Military Standard	MIL-DTL-5015
Mating Type	Bayonet
Connector Size	Standard
Shell Plating	Olive Drab Cadmium

Key Features

Supports 14 female contacts for secure and reliable connections.
Operates at a voltage of 500V AC and current of 13A.
Constructed with brass contacts plated in silver for optimal conductivity.
Features an olive drab cadmium plated aluminium alloy shell for corrosion resistance.
Designed for wall mount with bayonet mating type and solder termination.
Suitable for harsh environments with operating temperature range from -55°C to 125°C.
Meets military standard MIL-DTL-5015 for robust performance.
Includes strain relief and uses polychloroprene insulator for durability.

Product Description

Amphenol Limited 97B-3100A-22-19S MIL Spec Circular Connector is a rugged brass straight 14 way wall mount connector designed specifically for demanding industrial and military applications requiring secure electrical connections.

This connector features 14 female contacts made of brass, plated with hard silver over nickel to ensure excellent conductivity and durability. The connector supports a nominal voltage of 500V AC and a current rating of 13A, making it suitable for medium power applications.

The housing is crafted from an aluminium alloy with an olive drab cadmium finish providing robust corrosion resistance and mechanical protection. Designed to MIL-DTL-5015 military specifications, it ensures reliable operation in extreme conditions from -55°C to 125°C. The mounting type is wall mount with bayonet mating providing secure and quick connection and disconnection.

Termination is by solder, and the design includes strain relief to protect cables against mechanical stress. The polychloroprene insulator is employed inside for enhanced durability and environmental protection.

This connector's standard size 22 shell and straight orientation make it ideal for use in industrial, military, aerospace, and manufacturing settings where dependable circular connectors are essential for signal and power transmission.

Supports 14 female contacts for reliable connectivity. Operates at 500V AC voltage and 13A current rating. Brass contacts with silver plating enhance conductivity and corrosion resistance. Aluminium alloy shell with olive drab cadmium plating for robust protection.

Wall mount bayonet type for secure installation and mating. Wide operating temperature range from -55°C to 125°C for harsh environments. Meets MIL-DTL-5015 military connector specification standards. Includes strain relief features for cable protection.

Solder termination type assures solid electrical connections. Manufactured in India maintaining quality standards.

This Amphenol Limited MIL Spec Circular Connector is extensively used in military vehicles, aerospace equipment, industrial power systems, and test & measurement devices requiring a secure and rugged connection interface.

Explore the range of Mil Spec Circular Connectors in the Electronics & Electricals category at EnvMart for compatible and complementary products.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

It operates at a voltage of 500V AC and has a current rating of 13A.

This model supports 14 female contacts for secure and reliable connections.

The contacts are made of brass and plated with silver for optimal conductivity, while the housing is constructed from an aluminium alloy with an olive drab cadmium finish for corrosion resistance.

It can operate in a temperature range from -55°C to 125°C, making it suitable for harsh environments.

The connector features a solder termination type, ensuring solid electrical connections.

This model is designed for wall mount installation with a bayonet mating type for secure connections.

It meets the MIL-DTL-5015 military specifications, ensuring robust performance in demanding applications.

The connector has a standard size 22 shell, suitable for various applications.

The connector features an olive color due to its cadmium plating.

It is manufactured in India, maintaining quality standards.

It is extensively used in military vehicles, aerospace equipment, industrial power systems, and test & measurement devices.

It includes strain relief to protect cables against mechanical stress and uses a polychloroprene insulator for environmental protection.
