Amphenol Limited MIL Spec Circular Connector Brass Straight 3 Way Wall Mount Female Connector with Male 97B-3100A-22-2P
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 900V ac |
| Brand | Amphenol Limited |
| Colour | Olive |
| Orientation | Straight |
| Current | 46A |
| Model | 97B-3100A-22-2P |
| Mount Type | Wall Mount |
| Housing Material | Aluminium Alloy |
| Contact Material | Brass |
| Series | 97B |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Silver |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Connector Gender | Female |
| Shell Size | 22 |
| Military Standard | MIL-DTL-5015 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Shell Plating | Olive Drab Cadmium |
Key Features
- Rated for 46A current with a voltage capacity of 900V AC.
- Features male contacts and female connector gender with a bayonet mating type for secure connections.
- Constructed with aluminium alloy housing and olive drab cadmium plating for corrosion resistance.
- Operates reliably within a temperature range of -55°C to 125°C.
- Complies with MIL-DTL-5015 military standard ensuring ruggedness and reliability.
- The connector has strain relief and polychloroprene insulator for durability and secure installation.
- Suitable for industrial, military, aerospace, and electronic component assembly use cases.
- Compact shell size 22 with solder termination type enables precise cable mounting.
Product Description
Amphenol Limited 97B-3100A-22-2P MIL Spec Circular Connector is engineered for high durability and reliable electrical connections in demanding environments. This brass straight 3 way wall mount connector features a female olive drab cadmium plated shell with male contacts plated in silver over brass for superior conductivity and corrosion resistance. Rated at 46 amperes and 900 volts AC, the connector delivers secure and efficient power transfer.
Manufactured to MIL-DTL-5015 military specifications, the connector accommodates bayonet mating for rapid yet secure fittings. Its aluminium alloy housing with an olive colored finish protects against environmental damage, allowing operation in extreme temperatures from -55°C up to 125°C. The polychloroprene insulator and strain relief enhance durability and mechanical stability.
The 97B series offers a compact size 22 shell design, ideal for space-constrained applications in industrial equipment, aerospace systems, and military electronics. Solder termination type facilitates robust cable mounting ensuring longevity of connections under vibration or motion.
Rated for 46A current with 900V AC voltage tolerance. Brass contacts with silver plating for excellent conductivity. Bayonet locking mechanism for secure attachment. Wide operating temperature range from -55°C to 125°C. Durable aluminium alloy housing with olive drab cadmium plating.
Polychloroprene insulator enhances cable strain relief and durability. Wall mount design suitable for chassis panels and rugged installations. Meets MIL-DTL-5015 military specifications for standardized interconnects.
This connector is ideal for industrial, laboratory, military, aerospace, HVAC, and manufacturing applications requiring robust, high-current circular connectors. Designed for efficient electrical performance and environmental protection.
Explore more Mil Spec Circular Connectors on EnvMart for reliable electronic component solutions tailored to precision and durability needs.
