Murata Wirewound Surface Mount Inductor 0.1 μH ±10 % 1 A Idc Ferrite Core 1608 Package LQW18CNR10K00D
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Murata |
| Height | 0.8mm |
| Length | 1.6mm |
| Model | LQW18CNR10K00D |
| Depth | 0.8mm |
| Packaging | Paper Tape |
| Series | LQW |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 0.1μH |
| Standards/Approvals | RoHS |
| Package/Case | 1608 |
| Maximum DC Current | 1A |
| Pin Count | 2 |
| Maximum DC Resistance | 100mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 1.26GHz |
| Inductor Construction | Wirewound |
Key Features
- Compact 1608 package suitable for surface mount technology.
- Low DC resistance of 100 mΩ ensures efficient performance.
- High maximum self-resonant frequency of 1.26 GHz for RF applications.
- Constructed with ferrite core providing high Q value and reliable wirewound inductance.
- Operates reliably within temperature range -40°C to 85°C.
- RoHS compliant and moulded design for enhanced durability.
- Termination style is solder facilitating secure PCB mounting.
- Suitable for antenna matching circuits requiring stable inductance.
Product Description
Murata LQW18CNR10K00D is a wirewound surface mount inductor featuring a ferrite core, delivering a nominal inductance of 0.1 μH with ±10 % tolerance. Engineered for high-frequency circuits, it supports a maximum DC current of 1 A, making it ideal for RF choke and antenna matching applications. Its compact 1608 package (1.6 mm length × 0.8 mm height × 0.8 mm depth) is designed for surface mount technology, enabling high-density PCB layouts.
The inductor exhibits a low DC resistance of 100 milliohms, contributing to high efficiency and reduced power loss. With a maximum self-resonant frequency of 1.26 GHz, it performs effectively in high-frequency signal paths. The ferrite core construction provides excellent magnetic properties and high Q factor, enhancing attenuation characteristics inside filter pass bands.
This component operates within an ambient temperature range of -40°C to 85°C, ensuring reliability in diverse industrial and electronic environments. The moulded design adds mechanical robustness, while RoHS compliance assures environmentally friendly manufacturing standards.
The LQW18CNR10K00D comes in paper tape packaging, facilitating automated pick-and-place assembly processes. Termination via solder allows strong electrical and mechanical connection on printed circuit boards.
Compact 1608 package size suited for modern electronics manufacturing. Ferrite core offers high magnetic performance and stability. Wirewound construction providing low resistance and high Q factor. High self-resonant frequency enables RF and communication applications.
Wide operating temperature range supports varied industrial applications. RoHS compliant design adheres to environmental standards. Suitable for choke circuits and antenna filter matching. Reliable solder termination for surface mounting.
This Murata surface mount inductor is widely used in electronic component assemblies within industrial, telecommunications, automotive electronics, and consumer devices. Explore similar Inductors and electronic components within the Electronics & Electricals category at EnvMart for your design and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Murata LQW18CNR10K00D has a nominal inductance of 0.1 μH with a tolerance of ±10%.
This inductor supports a maximum DC current of 1 A.
It has a maximum self-resonant frequency of 1.26 GHz, making it suitable for high-frequency applications.
The dimensions of the 1608 package are 1.6 mm in length, 0.8 mm in height, and 0.8 mm in depth.
The inductor features a low DC resistance of 100 mΩ, which contributes to its efficiency.
It operates reliably within a temperature range of -40°C to 85°C.
The inductor is constructed with a ferrite core, which provides high magnetic performance.
The LQW18CNR10K00D comes in paper tape packaging, facilitating automated pick-and-place assembly processes.
It features a solder termination style, allowing for secure mounting on printed circuit boards.
Yes, this model is RoHS compliant, adhering to environmental standards for manufacturing.
This inductor is suitable for RF choke and antenna matching applications, among others in electronic component assemblies.
The Murata LQW18CNR10K00D belongs to the LQW series of inductors.
