Siemens Inverter Drive 2.2 kW 3 Phase SINAMICS G115D Series 480V 11.8 A 6SL3520-3XE02-2AF0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-3XE02-2AF0 |
| IP Rating | IP66, IP65 |
| Mount Type | Panel |
| Series | SINAMICS G115D |
| Overall Width | 380mm |
| Power Rating | 2.2kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 11.8A |
| Standards/Approvals | EAC, C-Tick (RCM), CE, SEMI F47, REACH, KCC |
| Maximum Supply Voltage | 480V |
| Overall Depth | 129mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
Key Features
- Integrated SINAMICS G115D series for high efficiency and reliable performance.
- Supports a maximum output current of 11.8 A at 480V supply voltage.
- Panel mount type with robust IP66 and IP65 protection ratings.
- Operates within a temperature range of -30°C to 55°C ensuring suitability for harsh environments.
- Enables output frequency up to 550Hz for versatile speed control capabilities.
- Designed for horizontal conveyor system applications with advanced encoderless vector control.
- Equipped with integrated safety features including Safe Torque Off (STO) with fail-safe digital inputs or PROFIsafe interface.
- Compact design reduces space requirements and eliminates the need for control cabinets.
Product Description
Siemens 6SL3520-3XE02-2AF0 inverter drive from the SINAMICS G115D series is a 2.2 kW power rated device designed for three-phase 480V electrical systems. It provides a maximum output current of 11.8 A and supports output frequencies up to 550Hz enabling precise speed control across various industrial applications.
This inverter drive is engineered for demanding environments with an operating temperature range from -30°C to 55°C and robust protection ratings of IP66 and IP65. Its panel mount design allows for easy installation on machines, reducing space requirements and cooling needs by eliminating traditional control cabinets.
The Siemens SINAMICS G115D drive system offers a modular, user-friendly solution optimized for horizontal conveyor system tasks, providing simple speed control to sophisticated encoderless vector control. Integrated safety features include Safe Torque Off (STO) with fail-safe digital input or PROFIsafe protocols, ensuring safe operation.
Constructed to support SIMOGEAR 2KJ8 geared motors, this drive works seamlessly with high-efficiency asynchronous motors classified as IE3, or synchronous reluctance motors classified as IE4. The unit is designed and manufactured in the United Kingdom, adhering to internationally recognized standards such as EAC, C-Tick (RCM), CE, SEMI F47, REACH, and KCC.
This inverter enables energy savings and enhanced operational efficiency in automation, manufacturing, conveyor systems, and HVAC applications. Integrated SINAMICS G115D series for high efficiency and reliable performance.
Supports a maximum output current of 11.8 A at 480V supply voltage. Panel mount type with robust IP66 and IP65 protection ratings. Operates within a temperature range of -30°C to 55°C ensuring suitability for harsh environments.
Enables output frequency up to 550Hz for versatile speed control capabilities. Designed for horizontal conveyor system applications with advanced encoderless vector control. Equipped with integrated safety features including Safe Torque Off (STO) with fail-safe digital inputs or PROFIsafe interface.
Compact design reduces space requirements and eliminates the need for control cabinets. Manufactured in the United Kingdom with compliance to EAC, C-Tick (RCM), CE, SEMI F47, REACH, and KCC standards. Explore Siemens Inverter Drives in the EnvMart catalog for more industrial-grade automation and control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Siemens inverter drive has a power rating of 2.2 kW.
This model supports a maximum output current of 11.8 A.
The inverter drive operates within a temperature range of -30°C to 55°C.
It enables an output frequency of up to 550Hz.
The inverter drive has protection ratings of IP66 and IP65.
This unit is designed for panel mounting.
It complies with EAC, C-Tick (RCM), CE, SEMI F47, REACH, and KCC standards.
The overall width is 380mm and the overall depth is 129mm.
It supports SIMOGEAR 2KJ8 geared motors and high-efficiency asynchronous motors classified as IE3, or synchronous reluctance motors classified as IE4.
It is equipped with Safe Torque Off (STO) with fail-safe digital inputs or a PROFIsafe interface for enhanced safety.
This inverter drive is manufactured in the United Kingdom.
It is designed for horizontal conveyor system applications and offers advanced encoderless vector control capabilities.
