RS PRO Surface Mount Fuse 40A, 80V Ceramic Body High Current Micro Fuse 240-8273

RS PRO 240-8273 Surface Mount Fuse is a ceramic-body micro fuse designed to provide high current protection at 40 Amps and 80 Volts. This fuse is engineered to reliably interrupt excessive current flow and protect sensitive electrical circuits in a variety of demanding applications.

Constructed with a robust ceramic body, it offers excellent thermal endurance and mechanical strength. The compact size of the fuse, measuring 7.3 mm by 5.8 mm by 4 mm, allows easy integration into dense electronic assemblies.

The fuse supports a breaking capacity of 1500 Amps, making it ideal for high current protection in industrial, commercial, and residential devices such as motors, air conditioners, pumps, and other electrical equipment. Its resistance of 0.0013 Ohms ensures minimal voltage drop during operation, aiding energy efficiency.

Operable in extreme temperature ranges from -55°C to +125°C, this fuse maintains reliability in harsh environments. Terminals are made of copper with tin plating to ensure excellent conductivity and corrosion resistance.

This product fully complies with RoHS, UL, and REACH standards, guaranteeing safety, environmental responsibility, and regulatory approval. It is manufactured in Taiwan, Province of China, ensuring high quality and performance consistency.

This fuse features a ceramic body for durability and heat resistance. It supports a breaking capacity of 1500A ensuring reliable protection against overcurrent. The fuse dimensions are compact with a height of 5.8 mm and a depth of 4 mm.

It has an operating temperature range from -55°C minimum to 125°C maximum. Constructed with copper and tin terminals for excellent conductivity. Complies with RoHS, UL, and REACH standards for safety and environmental compliance.

Suitable for use in motors, air conditioners, pumps, and various industrial and commercial electrical applications. Resistance value is low at 0.0013Ω to minimize power loss. Manufactured in Taiwan, Province Of China, ensuring quality production standards.

This fuse is essential for industrial, laboratory, HVAC systems, manufacturing equipment, water treatment facilities, and agricultural machinery where overcurrent protection is critical.
