Schneider Electric Acti9 Active iDT40 Series Residual Current Device 25A 1-Pole 30 mA Voltage Independent 230V ac A9TYAE625

Schneider Electric A9TYAE625 Residual Current Device is part of the Acti9 Active iDT40 series, designed for enhanced electrical safety in industrial, commercial, and residential electrical installations. It boasts a 25A current rating and is built for single-pole applications with a trip sensitivity of 30 mA, providing reliable earth leakage detection. Voltage independence at 230V ac ensures consistent operation under varying voltage conditions.

Engineered for DIN rail mounting, this device facilitates easy integration into electrical panels. The unit meets stringent international standards including EN/IEC 62606, EN/IEC 61009-1, and EN/IEC 61009-2-1, guaranteeing compliance with electrical safety norms.

The residual current device is designed with earth leakage protection type A-SI, offering protection against AC and pulsating DC earth faults. The compact build with dimensions 91mm (H) x 36mm (W) x 73mm (D) provides space efficiency in panel installations.

Key operational features include an LED arc fault diagnostic indicator and fault trip mechanism, which enhance fault detection and system diagnostics. The device operates reliably across a wide ambient temperature range of -25 to 60 °C and tolerates relative humidity levels up to 95% at 55 °C, ensuring robustness in diverse environments.

Electrical durability is rated for 10,000 cycles, supported by an impulse withstand voltage of 4 kV, making it suitable for demanding electrical conditions. Manufactured in Spain, this residual current device offers proven quality and durability for various applications including industrial automation, electrical distribution boards, and safety systems.

Installers and system designers will appreciate its integration ease, compliance with standards, and dependable protection capabilities. For detailed design and compliance documentation, technical datasheets and certificates are available through authorized channels.

Explore EnvMart's extensive range of Schneider Electric products and other Residual Current Devices to suit diverse electrical protection needs. Designed for DIN rail mounting for quick installation. Compliant with EN/IEC 62606, EN/IEC 61009-1, and EN/IEC 61009-2-1 standards.

Provides earth leakage protection type A-SI for AC and pulsating DC currents. Compact dimensions of 91mm height, 36mm width, and 73mm depth. Equipped with LED arc fault diagnostic indicator and fault trip function. Can operate in ambient conditions from -25 to 60 °C with 95% relative humidity tolerance at 55 °C.

Impulse withstand voltage rating of 4 kV ensures durability. Electrical endurance rated at 10,000 operation cycles. Manufactured in Spain to ensure quality and reliability.
