Infineon 2-Channel Class D Audio Amplifier IC 32-Pin Surface Mount 6W IRS2452AM

Infineon IRS2452AM is a 2-Channel Class D Audio Amplifier IC designed for high efficiency audio amplification in various audio equipment applications. This surface mount device features a 32-pin configuration with integrated high voltage Class D amplifier drivers and PWM modulators, enabling powerful 6W output while maintaining compact dimensions of 7mm by 7mm footprint and 0.9mm height.

The IC supports a broad operating voltage range from 15V minimum to 415V maximum supply voltage along with a wide operating temperature range from -55°C to 150°C, ensuring dependable operation under demanding conditions. It includes built-in protection controls such as programmable over current protection and an external thermal sensor input to safeguard the device during operation.

Designed with flexibility in mind, the IRS2452AM provides both differential and single-ended inputs suitable for half bridge amplifier configurations. Its programmable dead-time generation further optimizes performance and noise immunity in complex audio circuits.

This amplifier IC integrates a gain bandwidth product of 5MHz, making it ideal for precise audio amplification tasks, offering high noise immunity and reliable functionality in professional and consumer audio devices. The device complies with no specific automotive standards but is robust for general audio equipment use.

The amplifier integrates two high voltage, high performance Class D audio amplifier drivers with PWM modulators and protection features. Designed for half bridge applications with floating analog inputs and protection control interface pins.

Features external thermal sensor input for temperature monitoring and programmable dead-time generation. Provides differential or single-ended input options for versatile connectivity. Includes programmable over current protection to enhance reliability.

Supports operating temperatures from -55°C up to 150°C ensuring robust performance. Operates within a voltage range from 15V minimum supply up to a maximum of 415V supply voltage. Compact form factor: 7mm length, 7mm width, and 0.9mm height.

Gain bandwidth product of 5MHz suitable for audio amplification needs. Class D amplification technology offers efficient power utilization for audio systems.

This Infineon IRS2452AM audio amplifier IC is ideal for industrial, consumer electronics, laboratory, and commercial audio equipment requiring high efficiency, protection, and compact design. Explore more advanced semiconductor amplifiers at EnvMart to meet your design and manufacturing needs.
