Texas Instruments Current Loop Receiver 1-Channel 150 kHz 16-Pin PDIP 11.4V-22V RCV420JP

Texas Instruments RCV420JP Current Loop Receiver is a specialized semiconductor device designed for use in industrial automation and instrumentation applications. It supports 4mA-to-20mA current-loop communication, widely used for transmitting analog sensor data over distances exceeding 300 meters in electrically noisy environments. The device operates within a supply voltage range from 11.4 volts minimum to 22 volts maximum, providing robust power handling for industrial systems.

This single-channel current loop receiver features a slew rate of 1.5 volts per microsecond and a gain bandwidth product of 150 kHz, allowing for fast and accurate signal amplification. It provides an output current capacity of up to 4mA, making it suitable for driving subsequent signal processing stages.

The device's through-hole mount design in a 16-pin PDIP package facilitates straightforward incorporation onto printed circuit boards, enabling easier assembly and maintenance. It is engineered to operate reliably within a temperature range from minus 25 to 85 degrees Celsius, making it appropriate for harsh industrial conditions.

Physically, the receiver spans 19.3 millimeters in length and 4.57 millimeters in height, offering a compact footprint for space-constrained applications. Although it does not have specific industry or automotive approvals, it is widely used in electronics and electrical semiconductor applications focusing on data acquisition and control.

Operates between 11.4V and 22V supply voltage range. 1.5 V/μs slew rate ensures fast signal response. 150 kHz bandwidth supports accurate analog data transmission. 4mA output current suitable for signal conditioning. 16-pin PDIP package for easy PCB mounting.

Wide operational temperature range from -25°C to 85°C. Compact size: 19.3 mm length, 4.57 mm height. Designed for current loop communication in industrial environments. Ideal for applications in industrial automation, measurement, and sensor interfacing.

This Texas Instruments current loop receiver is essential for industrial, manufacturing, and automation systems requiring noise-immune analogue data transmission over long distances. Browse EnvMart’s extensive semiconductor and amplifier catalog to find compatible components and accessories.
