SMC 50 mm Double Acting Aluminium Alloy Cylinder CQ2 Series with Through Hole Mount CQ2B32TF-50DZ

The SMC CQ2B32TF-50DZ double acting cylinder is a premium pneumatic actuator from the CQ2 series by SMC, designed for efficient and reliable mechanical operation in industrial and automation settings.

This cylinder features a 50 mm stroke length and employs a double acting mechanism, allowing it to exert force during both extension and retraction. The body is constructed from durable aluminium alloy, ensuring a balance of strength and reduced weight. Its through hole mounting type enhances installation flexibility across various pneumatic and manufacturing applications.

Key technical specifications include a maximum piston speed of 500 mm/s and a maximum operating temperature rated up to 70°C, making it suitable for demanding environments such as manufacturing lines, assembly automation, and fluid power systems. The single rod utilizes a female piston rod thread with metric standards, facilitating secure and standardized connections to other components.

SMC’s CQ2 series cylinders are recognized for their compact design, achieving a weight reduction of 5 to 13 percent relative to previous models, which can contribute to overall machine weight reduction and improved productivity.

This model does not carry specific industry certifications or approvals but is manufactured in China to meet quality expectations. Its versatile features make it suitable for diverse industrial uses including pneumatic controlling, actuator tasks, automation, manufacturing plants, and fluid power tools in both commercial and heavy-duty settings.

Compact design reduces cylinder weight by 5-13% compared to previous models. Double acting action type provides robust pneumatic force for bidirectional operation. Stroke length of 50 mm supports a maximum piston speed of 500 mm/s for rapid actuation.

Single rod with female piston rod thread standard metric facilitates easy connection. Body made from aluminium alloy offers high strength with lightweight properties. Operational temperature limit up to 70°C suitable for demanding industrial environments.

Through hole mount type allows easy integration into machinery and equipment. Manufactured in China maintaining consistent quality standards. No certifications or specific approvals indicated for this product. Explore EnvMart’s extensive range of pneumatic cylinders and actuators to find compatible and complementary products suitable for your industrial automation needs.
