Samtec SSM Series Vertical Surface PCB Socket 40-Contact 2 Row 2.54 mm Pitch Solder SSM-120-L-DV-LC-M-TR
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 572V |
| Brand | Samtec |
| Orientation | Vertical |
| Current | 5.2A |
| Model | SSM-120-L-DV-LC-M-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | PCB Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 40 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Row Pitch | 2.5mm |
Key Features
- Constructed with liquid crystal polymer housing offering high durability.
- Supports current rating of 5.2 Amps for robust electrical performance.
- Female contact gender made of phosphor bronze with gold plating for excellent conductivity.
- Designed for board-to-board connector system with solder termination and vertical orientation.
- Operates reliably between -55°C and 125°C temperature range.
- Complies with SSM series standard, ensuring quality and consistency.
- Offers a row pitch of 2.5 mm for precise PCB alignment.
- Packaged in tape and reel format with 20 pins per row for easy SMT assembly.
Product Description
Samtec SSM-120-L-DV-LC-M-TR is a high-quality vertical surface mount PCB socket from the SSM series, designed for seamless board-to-board connections in electronic assemblies. Featuring 40 contacts arranged across 2 rows with a 2.54 mm pitch, it ensures reliable and precise electrical connections for industrial and commercial applications.
The housing is made of liquid crystal polymer, providing excellent mechanical strength and thermal resistance. The contacts are fabricated from phosphor bronze and plated with gold for superior conductivity and corrosion resistance. This connector supports a maximum current of 5.2 A and a voltage rating of 572 V, suitable for complex PCB designs requiring robust performance.
The socket operates within a temperature range of -55°C to 125°C, making it suitable for use in various industrial environments including manufacturing equipment, electronic instrumentation, and control systems. Its vertical orientation and solder termination type facilitate efficient surface mounting and integration onto printed circuit boards.
The package includes tape and reel format options, simplifying automated pick-and-place assembly processes with a locking clip and tiger claw SMT design. The 2.5 mm row pitch ensures correct alignment on PCBs, enhancing manufacturing accuracy.
Constructed with liquid crystal polymer housing for durability. High current capacity of 5.2 Amperes supports demanding electrical loads. Gold-plated phosphor bronze female contacts for reliable signal transmission. Vertical surface mount design ideal for board-to-board systems.
Wide operational temperature range from -55°C to 125°C. Includes locking clip and tape & reel packaging for SMT assembly. Compliance with Samtec's SSM series standards ensures quality.
This PCB socket is well-suited for industrial, laboratory, manufacturing, and commercial electronic equipment applications where secure, high-quality PCB connections are critical. Explore Samtec’s extensive product range and other electronic connector solutions at EnvMart for your design and production needs.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this model is 5.2 Amps, ensuring robust electrical performance for various applications.
This PCB socket has a voltage rating of 572 Volts, making it suitable for high-voltage applications.
The housing is made from liquid crystal polymer, while the contacts are fabricated from phosphor bronze and plated with gold for excellent conductivity.
It operates reliably within a temperature range of -55°C to 125°C, suitable for various industrial environments.
The SSM-120-L-DV-LC-M-TR features a total of 40 contacts arranged in 2 rows.
The pitch of the contacts is 2.54 mm, ensuring precise alignment on printed circuit boards.
This model utilizes a solder termination type, facilitating secure connections on PCBs.
The socket is designed with a vertical orientation, ideal for board-to-board connections.
It is packaged in a tape and reel format, which simplifies automated pick-and-place assembly processes.
This PCB socket complies with Samtec's SSM series standards, ensuring quality and consistency in its performance.
It is well-suited for industrial, laboratory, manufacturing, and commercial electronic equipment applications where secure PCB connections are critical.
The contact gender for this model is female, designed for reliable signal transmission.
