TDK-Lambda DC/DC Converter 15V DC 1.33A 18-36V DC Input 20W PCB Mount DIP Package PXD20-24S15

TDK-Lambda PXD20-24S15 DC/DC Converter is a high-performance voltage converter designed to provide a steady 15V DC output at a current of 1.33A with a maximum power output of 20 watts. This converter supports a wide input voltage range from 18V to 36V DC, making it suitable for diverse power supply conditions in industrial and electronic applications.

Featuring a robust DIP package with dimensions of 2 inches in length, 1 inch in width, and a depth of 10.2mm, it is designed for direct PCB mounting, enabling compact and efficient circuit board layouts.

The converter operates efficiently at 87%, minimizing power loss and heat generation while providing electrical isolation up to 1.6kV to protect circuits from transient voltages and noise interference. It is built to function reliably in extreme temperatures from -40°C up to 85°C, ensuring stability in demanding environments.

Additional protective features include short-circuit and over-voltage protections, enhancing operational safety and device longevity. The device has an MTBF rating of approximately 2,041,000 hours, indicating exceptional reliability for continuous usage over extended periods.

The low output ripple and noise of 75mV ensures the delivery of clean and stable power to sensitive electronic components, which is critical in precision industrial, laboratory, and communication equipment. The 6-pin DIP package further facilitates straightforward integration into existing PCB designs.

Supports wide 18V to 36V DC input voltage range for versatile applications. High efficiency of 87% reduces energy loss and heat generation. Isolation voltage of 1.6kV ensures electrical safety and noise reduction. Compact dimensions measuring 2 inches length, 1 inch width, and 10.2mm depth for easy PCB integration.

Operates in a broad temperature range from -40°C to 85°C suitable for harsh environments. Equipped with short-circuit and over-voltage protection features for enhanced reliability. MTBF of over 2 million hours guarantees long-term operational stability.

Low output ripple and noise of 75mV for stable power delivery to sensitive electronics. 6-pin DIP package type designed for PCB mount installation. Manufactured in Taiwan, Province of China, maintaining high build quality standards.
