TDK-Lambda CC-E Surface Mount DC/DC Converter 5V dc Output 1.2A, 6W, 9-18V Input, 85°C Max, -40°C Min CC6-1205SR-E

TDK-Lambda CC6-1205SR-E is a surface mount DC/DC converter designed for compact and efficient power supply conversion. Providing a stable 5V dc output at 1.2 Amperes and delivering up to 6 Watts of power, this converter supports input voltages between 9V and 18V dc. It is engineered to operate reliably between -40°C and 85°C, making it suitable for a wide range of industrial and commercial applications.

This DC/DC converter features a high isolation voltage of 500V, enhancing electrical safety by electrically isolating input and output. The device has an efficiency rating of approximately 82%, contributing to reduced heat generation and improved energy savings. Its compact footprint measures 22.86 mm in length, 22.8 mm in width, and 21.1 mm in depth, while weighing a mere 5.8 grams, which facilitates integration into space-constrained electronic assemblies.

Designed for single output voltage with a ±3% adjustment range, it supports a 7-pin surface mount package allowing for easy PCB integration. The unit’s 2:1 input to output ratio provides versatility in power conversion needs. Typical use cases include telecommunication equipment, industrial control systems, and consumer electronics requiring reliable DC voltage transformation with compact size and robustness.

Surface mount package for compact installation. Wide operating temperature range from -40°C to 85°C for harsh environments. High isolation voltage of 500V to ensure safety. Offers 82% efficiency for energy-efficient operation.

Single output with voltage adjustment range of ±3%. Small footprint with dimensions 22.86 x 22.8 x 21.1 mm. Lightweight design weighing only 5.8 g. Ideal for telecommunication, industrial, and consumer electronic applications.

Input to output ratio of 2:1 supports versatile power conversion. Reliable operation with 7-pin configuration.

TDK-Lambda products are designed with high quality and reliability, suitable for rigorous industrial environments. This CC-E series model CC6-1205SR-E is RoHS compliant and engineered in Japan, reflecting advanced engineering and manufacturing standards.
