TDK-Lambda CC-E DC/DC Converter, 3.3V DC Output, 800 mA, 18V Max Input, 9V Min Input, 3W Power, Surface Mount CC3-1203SR-E

TDK-Lambda CC3-1203SR-E DC/DC Converter is a compact and efficient power supply component designed for converting DC voltage levels with full electrical isolation. It outputs 3.3V DC at up to 800 mA and operates with an input voltage range between 9V and 18V, delivering 3W of output power in a surface mount package. This converter supports applications in telecommunications equipment, industrial automation, and consumer electronics requiring isolated power conversion.

The device features a high isolation voltage of 500V to protect sensitive circuits from electrical noise and surges. Its efficiency rating of 0.74% ensures minimal heat dissipation, supporting reliable long-term operation within a temperature range of -40°C to 85°C. The single output line offers a ±3% voltage adjustment for fine tuning output voltage to specific application needs.

The CC-E series converters by TDK-Lambda are known for their compact size, which allows integration into space-constrained PCBs. The surface mount design with a 7-pin layout facilitates automated assembly and low-profile installation. Weighing only 4.5 grams, the unit contributes minimal added weight to the overall system design.

RoHS compliance ensures that this product meets environmental standards for hazardous substance reduction, making it a sustainable choice for manufacturers. The origin of manufacture is Japan, underscoring high build and quality standards.

These DC/DC converters are ideal for a variety of industrial, telecom, laboratory, and commercial applications where reliable isolated power conversion is essential. The device’s features support compact, robust, and efficient electronic system designs needing stable DC voltage transformation.

Compact ultra small footprint for easy PCB integration. Wide operating temperature range from -40°C to 85°C. High isolation voltage of 500V for safety and noise reduction. High efficiency of 0.74% ensuring low heat generation.

Single output with ±3% output voltage adjustment range. Surface mount package providing low profile installation. Input voltage ratio of 2:1 supporting various input sources. Lightweight device with just 4.5 g mass for compact designs.

RoHS compliant, suitable for environmentally conscious designs. Reliable Japanese origin product with 7-pin configuration. Explore more DC/DC Converters in the Electronics & Electricals category at EnvMart for your power supply needs.
