TDK-Lambda CC-E Surface Mount DC/DC Converter, 12V DC Output 130mA, 9V DC Max Input, 3W Power, -40°C to 85°C CC3-0512DR-E

TDK-Lambda CC3-0512DR-E is a surface mount DC/DC converter designed to convert direct current from one voltage level to another with electrical isolation ensuring safety and performance. It delivers a stable 12V DC output with a current of 130mA and a maximum output power of 3W. Operating from an input voltage range of 4.5V to 9V DC, this converter provides efficient power conversion with an efficiency rating of 81%.

The device compactly fits into printed circuit boards using the Small Inline Package (SIP) with surface mount technology, occupying a small volume of 26.16 mm length, 22.8 mm width, and 16.6 mm depth. With a weight of only 4.5 grams, it is ideal for space- and weight-sensitive industrial and telecom applications.

Key electrical features include a dual output design with two outputs, including a negative 12V output, and an output voltage adjustment range of ±3% to fine tune system performance. A 500V isolation voltage provides electrical separation between input and output circuits, essential in preventing noise and protecting sensitive components.

The wide operating temperature range of -40°C to 85°C ensures reliable operation in demanding environments, making it suitable for industrial equipment, telecommunications infrastructure, and consumer electronics requiring compact and efficient power supplies.

Compact SIP package with surface mount technology for easy PCB integration. Offers dual output with an output voltage adjustment range of ±3%. Wide operating temperature from -40°C to 85°C ensures reliability in harsh environments.

High isolation voltage of 500V enhances safety and prevents interference. Efficiency rated at 81% for low power loss and thermal management. Ideal for telecommunications, industrial equipment, and consumer electronics applications.

Single and dual output configurations support versatile power supply designs. 7-pin configuration supports compact and reliable mounting. Compliance with RoHS standards ensures environmental safety. Product designed and manufactured in Japan, ensuring quality and reliability.

This DC/DC Converter is a top choice in industrial and electronic component markets where footprint, efficiency, and reliable operation under varied temperature conditions are critical. It supports multiple application uses, including embedded systems, telecom equipment power regulation, and other specialized electronic devices requiring isolated voltage conversion.
