TE Connectivity PCB Signal Relay 12V DC Coil 2A DPDT V23079-B1203-B301
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Height | 9.8mm |
| Length | 14.5mm |
| Model | V23079-B1203-B301 |
| Width | 7.2mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | Solder |
| Standards/Approvals | RoHS |
| Coil Resistance | 1029Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 220V dc |
| Switching AC Voltage | 250V ac |
| Coil Power | 140mW |
| Switching Power | 140mW |
| TE Connectivity PCB Signal Relay, 12V dc Coil, 2A, DPDTBrand | TE Connectivity |
| Panasonic PCB Mount Latching Relay, 12V dc Coil, DPDTBrand | Panasonic |
Key Features
- The relay is compact with dimensions of 14.5mm length, 9.8mm height, and 7.2mm width.
- It supports switching AC voltage up to 250V AC and DC voltage up to 220V DC.
- Gold plated bifurcated contacts ensure low contact resistance and enhanced reliability.
- Coil resistance is 1029Ω with a coil power of 140mW for energy-efficient operation.
- Designed for PCB mounting with solder terminal type, suitable for immersion cleaning with IP67 rating.
- Operating temperature range is from -40°C to 85°C, offering robust performance in varied environments.
- Standards compliance includes RoHS and Telcordia surge capability, ensuring industrial quality.
- Applications include communications, office equipment, consumer electronics, automotive, and medical devices.
Product Description
TE Connectivity V23079-B1203-B301 PCB Signal Relay is a miniature, high-sensitivity relay designed for efficient signal switching with low power consumption and compact dimensions. It offers a coil voltage of 12V DC and a switching current of 2A with a DPDT configuration, making it ideal for space-saving PCB applications in industrial and commercial electronics.
The relay features gold plated, bifurcated contacts with a coil resistance of 1029Ω and coil power of only 140mW, ensuring durability and energy efficiency. Its compact form factor with dimensions 14.5mm length, 9.8mm height, and 7.2mm width allows seamless integration into densely packed circuit boards.
Designed for reliable performance, the relay supports switching of AC voltage up to 250V and DC voltage up to 220V. It has a wide operating temperature range from -40°C to 85°C with IP67-rated immersion cleanability and a V-0 flammability classification, suitable for harsh industrial environments.
Standards adherence includes RoHS compliance and surge capability meeting Telcordia TR-NWT-001089 and IEC 60950 norms, validating its quality and safety for telecom and automation equipment.
This relay is suited for use in communications equipment such as PABX and VOIP systems, consumer electronic devices like set top boxes and hi-fi equipment, office machinery, automotive electronics, medical devices, and various control applications.
The relay is a 2 pole polarized telecom signal relay with reliable performance. Bifurcated, gold plated contacts increase contact reliability and reduce resistance. Designed for PCB mounting with solder terminals and can withstand immersion cleaning.
Wide temperature tolerance from -40°C to 85°C ensures operation in diverse conditions. Complies with RoHS and telecom surge test standards ensuring safety and regulatory compliance. Compact size supports space-saving designs in electronics and automation.
Ideal for industrial, medical, automotive, consumer electronics, and office equipment applications. Explore more Signal Relays and similar products at EnvMart for your electronic and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is 12V DC.
This model can handle a maximum switching current of 2A.
The relay has dimensions of 14.5mm in length, 9.8mm in height, and 7.2mm in width.
It can switch AC voltage up to 250V and DC voltage up to 220V.
This relay is designed for PCB mounting with solder terminals.
The coil resistance is 1029Ω.
The operating temperature range is from -40°C to 85°C.
The contacts are made of gold plated material, which enhances reliability.
This relay complies with RoHS and has Telcordia surge capability.
It is suitable for applications in communications, office equipment, consumer electronics, automotive, and medical devices.
The coil power consumption is 140mW.
The relay has a V-0 flammability classification, indicating it meets stringent safety standards.
