Eaton Contactor Relay 690V AC Coil, 32 A, 15 kW, Direct Mount ZBT65-32 190944 190944 ZBT65-32

Free Delivery in India | Lowest Global Shipping Charges

Eaton Contactor Relay 690V AC Coil, 32 A, 15 kW, Direct Mount ZBT65-32 190944 190944 ZBT65-32

Name: Eaton Contactor Relay 690V AC Coil, 32 A, 15 kW, Direct Mount ZBT65-32 190944 190944 ZBT65-32
Brand: Eaton
SKU: 163894
Price: 162.38 USD
Availability: InStock



Category Contactor Relay Brand Eaton Condition New

Specifications

Country of Origin	China
Brand	Eaton
Length	84mm
Model	190944 ZBT65-32
Depth	98mm
Width	56mm
Mount Type	Direct
Series	ZBT
Power Rating	15kW
Maximum Operating Temperature	40°C
Minimum Operating Temperature	-5°C
Standards/Approvals	GB14048, IEC/EN 60947
Coil Voltage	690V ac
Normal State Configuration	1 NO/1 NC
Contact Current	32A
Number of Auxiliary Contacts	2
Auxiliary Contact Configuration	1 NO/1 NC
Operational Current Ie	32A
Control Circuit Voltage Uc	690V

Key Features

Operates with a coil voltage of 690V AC for reliable performance.
Rated contact current of 32 amperes, supporting up to 15 kW power rating.
Direct mount type suitable for efficient installation.
Includes 1 normally open and 1 normally closed auxiliary contacts configuration.
Operates effectively between temperatures -5°C and 40°C.
Complies with GB14048 and IEC/EN 60947 standards.
Has a control circuit voltage of 690V and total 2 auxiliary contacts.

Product Description

Eaton 190944 ZBT65-32 contactor relay is a robust industrial component intended for electrical automation, control gear, and relay applications. It features a 690V AC coil voltage, 32A contact current rating, and a power rating of 15 kW suitable for various demanding industrial scenarios.

This contactor relay is constructed for direct mounting and includes 1 normally open (NO) and 1 normally closed (NC) auxiliary contact configuration, providing enhanced control circuit flexibility. The relay operates reliably within an ambient temperature range of -5°C to 40°C, making it suitable for industrial environments with moderate temperature variations.

Manufactured to comply with international standards including GB14048 and IEC/EN 60947, this Eaton relay assures quality and safety. The compact size dimensions of 84mm length, 56mm width, and 98mm depth facilitate easy integration into electrical panels and systems.

The coil control circuit voltage is 690V, consistent with the coil rating, ensuring consistent performance. This model forms part of the ZBT series and includes two auxiliary contacts configured as 1 NO and 1 NC. It is designed to operate effectively in industrial, manufacturing, automation, and electrical control applications.

Reliable and efficient, the Eaton ZBT65-32 Contactor Relay is suited for applications where safety, compliance, and operational excellence are critical. Its direct mount design simplifies installation in control panels and switchgear assemblies.

Operates with a coil voltage of 690V AC for reliable performance. Rated contact current of 32 amperes, supporting up to 15 kW power rating. Direct mount type suitable for efficient installation. Includes 1 normally open and 1 normally closed auxiliary contacts configuration.

Operates effectively between temperatures -5°C and 40°C. Complies with GB14048 and IEC/EN 60947 standards. Compact dimensions: 84mm length, 56mm width, and 98mm depth. Has a control circuit voltage of 690V and total 2 auxiliary contacts.
