MEAN WELL WDR-60-12 Switched Mode DIN Rail Power Supply 60W, 57V DC Output, 180-550V AC/DC Input, 5A Output Current
Specifications
| Country of Origin | China |
|---|---|
| Brand | MEAN WELL |
| Power | 60W |
| Efficiency | 86.5% |
| Height | 125.2mm |
| Model | WDR-60-12 |
| Depth | 102mm |
| Width | 32mm |
| Series | WDR-60 |
| Output Current | 5A |
| Maximum Operating Temperature | 85°C |
| Sub Type | Switched Mode |
| Minimum Operating Temperature | 30°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 780, 550V dc |
| Maximum Output Voltage | 57V dc |
| Minimum Input Voltage | 180V ac |
Key Features
- Compact slim design with a narrow width of 32mm for space-saving installation.
- Wide operating temperature range from -30°C to +85°C suitable for harsh environments.
- High efficiency of 86.5% ensures low energy loss during operation.
- Supports remote signal DC-OK for system monitoring and diagnostics.
- Built-in protections against overload, overvoltage, and short circuit for safe usage.
- Can be mounted easily on TS-35/7.5 or TS-35/15 DIN rails in industrial setups.
- High isolation voltage of 4KVAC provides enhanced safety in electrical installations.
- Supports operation at altitudes up to 2000m without derating.
Product Description
MEAN WELL WDR-60-12 is a switched mode DIN rail power supply delivering 60 watts of power with a regulated 57V DC output and 5A current capacity. It features a wide AC/DC input voltage range of 180 to 550V AC and DC, making it compatible with various single-phase or two-phase electrical systems.
The unit is designed for industrial and commercial use with a slim 32mm width, allowing for efficient space utilization on TS-35/7.5 or TS-35/15 mounting rails. It operates reliably in harsh environments with a broad temperature range from -30°C to +85°C and can perform without derating at altitudes up to 2000 meters.
This power supply incorporates comprehensive electrical protections including overload, overvoltage, and short circuit safeguards, alongside a high isolation voltage rating of 4KVAC to ensure operator safety and system integrity.
With an efficiency rating of 86.5%, the WDR-60-12 offers energy-efficient operation, minimizing power losses and heat generation. The output voltage is adjustable up to +20% maximum to accommodate specific load requirements, and it supports remote DC-OK signaling for system status monitoring.
Its robust design and flexibility make it ideally suited for industrial automation, telecommunications, surveillance systems, and other demanding applications requiring stable power supply on DIN rails.
Compact slim design with narrow width for space saving. Wide operating temperature ensures reliability. High efficiency reduces energy consumption. Remote DC-OK signal for operational monitoring. Complete protective functions for safe use.
Easy DIN rail mount installation. High isolation voltage for electrical safety. Altitude operation up to 2000 meters. Adjustable output voltage for flexibility. Suitable for diverse industrial applications. Explore more high-quality DIN Rail Power Supplies and related MEAN WELL products in the Power Supplies category on EnvMart for your industrial and commercial power needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The WDR-60-12 provides a regulated output voltage of 57V DC.
The maximum input voltage for the WDR-60-12 is 550V AC/DC.
This power supply has an efficiency rating of 86.5%.
It operates within a temperature range of -30°C to +85°C.
The WDR-60-12 can supply a maximum output current of 5A.
This model has dimensions of 125.2mm in height, 102mm in depth, and 32mm in width.
It can be easily mounted on TS-35/7.5 or TS-35/15 DIN rails.
This power supply includes protections against overload, overvoltage, and short circuit.
Yes, the output voltage is adjustable up to +20% maximum to accommodate specific load requirements.
The isolation voltage rating for this model is 4KVAC, enhancing safety in electrical installations.
It is suitable for industrial automation, telecommunications, surveillance systems, and other demanding applications requiring stable power.
