Hirose FX Series 40-Contact Female Interface Module Receptacle Connector Panel Mount 300V AC 500mA FX2B-40SA-1.27R

Free Delivery in India | Lowest Global Shipping Charges

Hirose FX Series 40-Contact Female Interface Module Receptacle Connector Panel Mount 300V AC 500mA FX2B-40SA-1.27R

Name: Hirose FX Series 40-Contact Female Interface Module Receptacle Connector Panel Mount 300V AC 500mA FX2B-40SA-1.27R
Brand: Hirose
SKU: 156833
Price: 6.6 USD
Availability: InStock



Category Interface Modules Brand Hirose Condition New

Specifications

Country of Origin	Indonesia
Voltage	300V ac
Brand	Hirose
Orientation	Straight
Current	500mA
Length	40.53mm
Model	FX2B-40SA-1.27R
Depth	19.1mm
Connector Type	Receptacle
Width	7mm
Gender	Female
Mount Type	Panel
Series	FX
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-55°C
Wire size	28AWG
Number of Contacts	40

Key Features

This interface module features 40 contacts with a 1.27mm pitch for multi-function connectivity.
The connector type is receptacle with a straight orientation, suitable for panel mount applications.
Supports wire size up to 28 AWG with a maximum current rating of 500mA and voltage of 300V AC.
Operates reliably in temperatures ranging from -55°C to 85°C.
The module measures 40.53mm length, 7mm width, and 19.1mm depth, ensuring compact design compliance.
Constructed with a robust design to prevent flux penetration and mis-insertion, enhancing reliability.
Easy one-touch operation facilitates fast and secure connections in industrial applications.
These connectors are part of the Hirose FX series, manufactured in Indonesia.

Product Description

Hirose FX2B-40SA-1.27R is a high-quality 40-contact female interface module designed for panel mounting applications. With a 1.27mm pitch and rated for 300V AC and 500mA current handling, this receptacle connector provides reliable multi-function connection solutions for electronic and power systems. Its straight orientation and compatibility with 28 AWG wire size make it ideal for precise signal and power transmission in compact assemblies.

Designed to withstand harsh environments, it operates seamlessly within a temperature range of -55°C to 85°C, ensuring durability and stable performance. The connector's dimensions of 40.53mm length, 7mm width, and 19.1mm depth allow easy integration into electronic components and control panels.

This interface module features a robust construction with mechanisms to prevent flux penetration during soldering and to avoid mis-insertion issues, enhancing operational safety and longevity. The easy one-touch operation streamlines installation and maintenance processes.

Hirose's FX series connectors are widely used in industrial, electronic, laboratory, and manufacturing environments to ensure secure and efficient connections. Manufactured in Indonesia, these connectors conform to high-quality standards without formal certifications but maintain a focus on functional reliability.

40-contact female interface with 1.27mm pitch for precise connectivity. Supports 28 AWG wires with a 500mA current rating and 300V AC voltage tolerance. Panel mount receptacle type with straight connector orientation. Wide operating temperature range from -55°C to 85°C.

Compact dimensions of 40.53mm x 7mm x 19.1mm. Robust design prevents flux penetration and mis-insertion, improving durability. Easy one-touch operation for efficient assembly and maintenance. Part of the reputable Hirose FX series, made in Indonesia.

This product is suited for demanding industrial and electronic applications, including control panels, automation systems, and power distribution setups. Explore more Hirose connectors and Interface Modules at EnvMart for reliable component solutions.
