HARTING Han E AV Series 24-Contact Male Interface Module Cable 16A 500V 09330244625

Free Delivery in India | Lowest Global Shipping Charges

HARTING Han E AV Series 24-Contact Male Interface Module Cable 16A 500V 09330244625

Name: HARTING Han E AV Series 24-Contact Male Interface Module Cable 16A 500V 09330244625
Brand: HARTING
SKU: 172502
Price: 131.39 USD
Availability: InStock



Category Interface Modules Brand HARTING Condition New

Specifications

Country of Origin	India
Voltage	500V
Brand	HARTING
Orientation	Horizontal
Current	16A
Length	34mm
Depth	34mm
Width	34mm
Gender	Male
Mount Type	Cable
Series	Han E AV
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Wire size	14, 24AWG
Number of Contacts	24
Cable CSA	0.2, 2.5mm²

Key Features

This interface module supports 24 contacts for comprehensive wiring needs.
Rated current capacity of 16 amperes ensures robust power handling.
Cable mount type facilitates flexible horizontal installation in industrial environments.
Operates effectively within a temperature range of -40°C to 125°C.
Compatible with Han E AV hood and housing series for custom installations.
Supports wire sizes from 14 to 24 AWG and cable cross-sectional areas between 0.2 and 2.5 mm².
Designed for mechanical durability with a lifespan of up to 500 mating cycles.
Ideal for use in industrial, electronic, and power connector applications.

Product Description

HARTING 09330244625 Han E AV Series 24-Contact Male Interface Module cable is engineered for reliable and customizable electrical connections rated for 16 amperes and 500 volts. Designed to be used with compatible Han E AV series hoods and housings, it supports a horizontal cable mounting style suitable for demanding industrial and electronic applications.

The module accommodates 24 contacts allowing extensive wiring capability, and supports wire sizes from 14 to 24 AWG with cable cross-sectional areas from 0.2 to 2.5 mm². Its mechanical construction ensures a long service life, rated for 500 mating cycles, providing durability and dependability in repetitive connection applications.

Operating smoothly within a temperature range from -40 degrees Celsius to 125 degrees Celsius, this male interface module meets the work environment requirements of many industrial, manufacturing, and power distribution systems. Although specific approval standards are not cited, the design and robust performance configuration make it an essential component for power and electronic connector needs.

This interface module supports 24 contacts for comprehensive wiring needs. Rated current capacity of 16 amperes ensures robust power handling. Cable mount type facilitates flexible horizontal installation in industrial environments.

Operates effectively within a temperature range of -40°C to 125°C. Compatible with Han E AV hood and housing series for custom installations. Supports wire sizes from 14 to 24 AWG and cable cross-sectional areas between 0.2 and 2.5 mm².

Designed for mechanical durability with a lifespan of up to 500 mating cycles. Ideal for use in industrial, electronic, and power connector applications. Constructed to comply with safety standards though no explicit certifications are listed.

This interface module is widely used in electronics manufacturing, industrial automation, power supply systems, and electronic component assembly environments requiring sturdy and versatile connection modules. Its compatibility with Han E AV accessories facilitates tailored configurations for specific application needs.
