Amphenol Communications Solutions Quickie Series Right Angle Through Hole PCB Header 50 Contacts 2.54 mm Pitch 75867-108LF

Amphenol Communications Solutions 75867-108LF is a Quickie Series right angle through hole PCB header designed for demanding electronic assembly applications. Featuring 50 male contacts arranged in two rows with a 2.54 mm pitch, this shrouded header provides secure, high-reliability wire-to-board connections on printed circuit boards.

Constructed from phosphor bronze contact material with 0.76 μm gold plating, it delivers excellent electrical conductivity and resistance to corrosion, ensuring signal integrity across extended operational lifespans. The right angle orientation aids in flexible PCB layout designs, accommodating complex electronic configurations within constrained spaces.

The header supports a continuous current of up to 3 amperes and voltage rating of 500 volts, specifying suitability for moderate power applications such as industrial controls, communication equipment, and computing hardware. Its robust through hole mount and solder termination guarantee mechanical stability and reliable electrical contact under typical manufacturing stresses.

Engineered to operate reliably in varied environments, the component supports a wide temperature range from -65°C to +125°C, making it suitable for both industrial and commercial applications. The 3.05 mm tail pin length ensures strong solder joints, optimizing durability and performance over multiple thermal cycles.

This product is manufactured in France, adhering to solid quality standards though no explicit certifications are noted. The shrouded design enhances connection security and prevents accidental pin damage or misalignment during mating procedures.

Double row, 50-position PCB header with 2.54 mm pitch. Right angle orientation optimized for wire-to-board interconnections. Phosphor bronze contacts with gold plating for performance and longevity. Rated for 3A current and 500V voltage.

Operating temperatures from -65°C to 125°C accommodate diverse industries. Through hole solder termination mount ensures reliable mechanical support.

This Amphenol Quickie Series PCB header is ideal for applications in electronics manufacturing, industrial automation, communication devices, and computing equipment. It supports rigorous industrial demands while maintaining precision and durability, making it a trusted component for engineers and designers.
