Yageo 22 pF 50V dc ±1 % Multilayer Ceramic Capacitor Surface Mount 0603 CC0603FRNPO9BN220

The Yageo CC0603FRNPO9BN220 is a multilayer ceramic capacitor specifically engineered for precision performance in various electronic applications. This 22 pF capacitor features a tight tolerance of ±1 %, ensuring stable and accurate capacitance values critical for RF circuits, tuning applications, and frequency stabilizing components.

Designed for surface mount technology, it comes in a compact 0603 package with dimensions 1.6mm length, 0.8mm width, and 0.8mm height. The stacked construction along with a C0G dielectric material provides low losses, high stability over temperature, and excellent aging characteristics. This makes the capacitor ideal for use in consumer electronics such as television receivers, cameras, telecommunication devices, and tuners.

The CC0603FRNPO9BN220 capacitor supports an operating voltage up to 50V dc and a temperature range from -55°C to 125°C, making it suitable for demanding environmental conditions. Its surface mount termination with a nickel barrier end termination yields high solderability and reliable mechanical strength.

This component is supplied on a paper/PE tape reel, compatible with automated pick-and-place machines, facilitating efficient high-volume production workflows. It conforms with IEC 60384-1 and IEC 60384-21/22 international standards, guaranteeing quality and consistency.

The capacitor is RoHS and Halogen Free compliant, supporting sustainable practices in electronics manufacturing. It is a standard series capacitor, classified as Class I suppression class, making it a versatile choice for many industrial and commercial electronic equipment applications.

Provides a capacitance of 22 pF with a tight tolerance of ±1 % for high accuracy. Rated for a maximum operating voltage of 50V dc, suitable for low voltage circuits. Constructed with a stacked design and C0G dielectric ensuring stable performance across temperature variations.

Surface mount termination type with a 0603 package size allowing compact PCB layout. Capable of operating within a temperature range of -55°C to 125°C for harsh environments. Compliant with RoHS and Halogen Free standards, supporting environmentally safe electronics manufacturing.

Supplied on paper/PE tape reel format optimized for automated assembly processes. Meets international standards IEC 60384-1 and IEC 60384-21/22 for quality and reliability.

This Multilayer Ceramic Capacitor is essential for use in industrial, consumer electronics, telecommunications, and manufacturing applications requiring stable and precise capacitance values. Explore more Yageo capacitors and electronic components in the EnvMart catalogue for tailored solutions.
