HOBUT Analogue Panel Ammeter 100 A AC, 72 mm x 72 mm, Class 1.5 Moving Iron D72SD

Free Delivery in India | Lowest Global Shipping Charges

HOBUT Analogue Panel Ammeter 100 A AC, 72 mm x 72 mm, Class 1.5 Moving Iron D72SD

Name: HOBUT Analogue Panel Ammeter 100 A AC, 72 mm x 72 mm, Class 1.5 Moving Iron D72SD
Brand: HOBUT
SKU: 154641
Price: 30.74 USD
Availability: InStock



Category Analogue Panel Ammeter Brand HOBUT Condition New

Specifications

Country of Origin	United Kingdom
Brand	HOBUT
Operating Temperature Range	- 25 to +40°C
Model	D72SD
Depth	38.5mm
Series	D72SD
Maximum Operating Temperature	40°C
Current Type	AC
Meter Accuracy	Class 1.5
Minimum Operating Temperature	-25°C
Standards/Approvals	DIN 43802, IEC 51, UL94V1, BS 89, UL94V0, DIN 43700
Cutout Height	72mm
Cutout Width	72mm
Minimum Measurement	0 A
Moving Element	Moving Iron
Maximum Ampere Value	100 A
Panel cut out	45 x 45mm, 68 x 68mm, 92 x 92mm
RS PRO Analogue Panel Ammeter 10 A AC, 68 mm x 68 mm, 1 % Moving IronBrand	RS PRO

Key Features

Designed for AC current measurement up to 100 A with moving iron technology.
Compact panel size of 72 mm by 72 mm allows easy integration.
Measurement accuracy class 1.5 ensures reliable readings.
Operating temperature range from -25°C to 40°C supports various industrial environments.
Constructed with flame retardant case to UL94V0 standards.
Compliant with DIN 43802, IEC 51, BS 89 standards for quality assurance.
Supplied with mounting brackets for secure installation.
Panel cutout sizes compatible with 45x45 mm, 68x68 mm, and 92x92 mm configurations.

Product Description

HOBUT D72SD Analogue Panel Ammeter 100 A AC is a robust and precise instrument designed for industrial and laboratory AC current measurement applications. Equipped with a moving iron mechanism and an accuracy class of 1.5, this ammeter delivers reliable readings for currents up to 100 Amperes.

The instrument features a compact and standardized panel size of 72 mm by 72 mm, making it suitable for panel mounting in control rooms, automation systems, electrical panels, and process control environments. It maintains performance across a broad operating temperature range from -25°C to +40°C, ensuring stable function even in challenging conditions.

Manufactured in the United Kingdom, the ammeter complies with international standards DIN 43802, IEC 51, BS 89, and UL94 flame retardant specifications (V0 rating), emphasizing its high safety and quality standards. The flame-retardant casing enhances usability in industrial settings where safety compliance is critical.

Installation is facilitated by included mounting brackets and supports several panel cutout dimensions: 45 x 45 mm, 68 x 68 mm, and 92 x 92 mm. Terminal covers are available separately as accessories to increase operational safety.

This ammeter is ideal for electrical panels, automation systems, industrial machines, HVAC controls, and manufacturing processes requiring direct reading of AC current with dependable precision and rugged reliability.

Designed for AC current measurement up to 100 A with moving iron technology. Compact panel size of 72 mm by 72 mm allows easy integration. Measurement accuracy class 1.5 ensures reliable readings. Operating temperature range from -25°C to 40°C supports various industrial environments.

Constructed with flame retardant case to UL94V0 standards. Compliant with DIN 43802, IEC 51, BS 89 standards for quality assurance. Supplied with mounting brackets for secure installation. Panel cutout sizes compatible with 45x45 mm, 68x68 mm, and 92x92 mm configurations.
