ITT Cannon Circular Connector 7 Contacts Cable Socket Female IP67 Sure Seal Series 120-8551-007

ITT Cannon 120-8551-007 circular connector is a high-quality industrial connector with 7 contacts designed for cable mounting applications. This standard size socket type connector features a robust Perbunan housing and tin-plated copper alloy contacts, providing excellent conductivity and resistance to corrosion. Rated for 8A current per contact and 1200V voltage, it is engineered for reliable, durable connections in demanding environments.

The Sure Seal series ensures IP67 rating, making these connectors fully protected against dust ingress and temporary water immersion. The connector is resistant to automotive fluids including brake fluid, diesel fuel, and anti-freeze, and withstands steam cleaning processes. Its bayonet mating system paired with a polarized mechanical design prevents mismating, ensuring secure and repeatable connections with up to 50 mating cycles.

Operating temperature range from -40°C to 105°C makes this connector ideal for various industrial automation, commercial electronics, and automotive applications. The straight body orientation and crimp termination allow for straightforward installation and reliable cable connections. Although contacts need to be ordered separately, this connector provides an efficient solution for rugged and compact interconnect needs.

This connector provides a current rating of 8A per contact for reliable power transmission. Constructed with Perbunan housing and tin-plated copper alloy contacts for durability. Operates within a temperature range of -40°C to 105°C for versatile industrial applications.

Designed with bayonet mating type and straight orientation ensuring secure connections. Resistant to brake fluid, anti-freeze, fuels, and steam cleaning, suitable for automotive and industrial use. Polarized to prevent mismatching, supporting up to 50 mating cycles with wire insulation sealing of 1.8-2.8mm.

Part of the Sure Seal series, it meets IP67 standards for water and dust ingress protection. For more industrial-grade circular connectors and accessories, browse through EnvMart's extensive Electronics & Electricals categories.
