Mersen 125A Bolted Tag Fuse B2 690V AC, Central Bolted Tag Fuse-links gM Series H1006625 / BTF69V125M200
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 690V ac |
| Diameter | 41.9mm |
| Brand | Mersen |
| Height | 73mm |
| Length | 73mm |
| Model | H1006625 / BTF69V125M200 |
| Width | 41.9mm |
| Overall Length | 138mm |
| Current Rating | 125A |
| Series | Central Bolted Tag Fuse-links gM 690VAC/460VDC |
| Standards/Approvals | CE, IEC 60269, BS 88, REACH, EN 60269-2, RoHS |
| Fuse Size | B2 |
| Fixing Centres | 111 mm |
| Tag Width | 19.5mm |
| Tag Orientation | Centred |
| Application Category | gM |
Key Features
- Rated current of 125A ensures reliable protection for electrical circuits.
- Fuse size B2 with fixing centres measuring 111 mm for secure installation.
- Complies with CE, IEC 60269, BS 88, REACH, EN 60269-2, and RoHS standards for safety and environmental requirements.
- Tag width is 19.5 mm with a centred tag orientation for easy fixing and replacement.
- High rupture capacity not supported, designed for gM category applications.
- Manufactured in India ensuring quality and compliance.
Product Description
Mersen H1006625 / BTF69V125M200 is a 125A Bolted Tag Fuse B2 designed for high-performance electrical protection under a voltage rating of 690V AC. This Central Bolted Tag Fuse-links series is tailored for gM application category, offering robust motor protection and general purpose use across industrial, commercial, and manufacturing settings.
The fuse delivers excellent current limitation on all overload conditions, enhancing system safety and reliability. It features a fuse size of B2 and fixing centres of 111 mm which facilitate firm mounting via bolting directly onto busbars or fuse holders. The centred tag orientation and 19.5 mm tag width ensure secure and accessible connections.
Key dimensions of this fuse include a length of 73 mm, overall length of 138 mm, height of 73 mm, and a diameter of 41.9 mm, making it compatible with standard fuse holders and interruptors. While it does not support a high rupture capacity, it fulfills stringent standards and approvals such as CE, IEC 60269, BS 88, REACH, EN 60269-2, and RoHS, which validate its safety, environmental compliance, and performance.
This bolted tag fuse is ideally applied in motor protection and general electrical circuit safeguarding tasks in industrial installations, water treatment plants, manufacturing plants, and HVAC systems. Manufactured in India, it represents reliable quality adhering to international norms.
Rated at 125A current for reliable overcurrent protection. Fuse size B2 with fixing centres of 111 mm for secure installation. Voltage rating of 690V AC suitable for industrial use. Conforms to multiple international safety and environmental standards.
Compact dimensions for easy integration into existing systems. Centred tag orientation with a 19.5 mm tag width. Part of the Central Bolted Tag Fuse-links gM 690VAC/460VDC series. Manufactured in India ensuring quality and compliance.
Explore EnvMart's comprehensive selection of electrical protection devices to find complementary fuses and circuit breakers meeting diverse specifications and industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The bolted tag fuse has a current rating of 125A, providing reliable protection for electrical circuits.
It is rated for a voltage of 690V AC, making it suitable for industrial applications.
The fuse measures 73 mm in length, 73 mm in height, and has an overall length of 138 mm with a diameter of 41.9 mm.
This model has a fuse size of B2 and fixing centres measuring 111 mm for secure installation.
It complies with multiple standards including CE, IEC 60269, BS 88, REACH, EN 60269-2, and RoHS for safety and environmental requirements.
The tag width is 19.5 mm, and it features a centred tag orientation for easy fixing and replacement.
It is designed for motor protection and general electrical circuit safeguarding in industrial installations, manufacturing plants, and HVAC systems.
It is manufactured in India, ensuring quality and compliance with international norms.
This model belongs to the Central Bolted Tag Fuse-links gM 690VAC/460VDC series.
No, this fuse does not support high rupture capacity and is designed for gM category applications.
The overall length of this bolted tag fuse is 138 mm.
The centred tag orientation allows for secure and accessible connections during installation and replacement.
