Siemens NH Fuse 315A 1kV High Rupture Capacity Semiconductor Protection Fuse 3NE3230-0B

Free Delivery in India | Lowest Global Shipping Charges

Siemens NH Fuse 315A 1kV High Rupture Capacity Semiconductor Protection Fuse 3NE3230-0B

Name: Siemens NH Fuse 315A 1kV High Rupture Capacity Semiconductor Protection Fuse 3NE3230-0B
Brand: Siemens
SKU: 117660
Price: 316.27 USD
Availability: InStock



Category Tag Fuse Brand Siemens Condition New

Specifications

Country of Origin	Greece
Voltage	1kV
Brand	Siemens
Height	63.5mm
Length	73mm
Model	3NE3230-0B
Width	52mm
Overall Length	135mm
Current Rating	315A
Series	3NE
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-20°C
Fuse Size	NH1
Fixing Centres	110 mm
Tag Width	12.5mm
Application Category	aR
Tag Type	Slotted

Key Features

Rated current of 315A ensuring robust electrical protection.
Designed to operate at a voltage of 1kV suitable for medium voltage applications.
Fuse size NH1 with 110 mm fixing centres for easy installation.
Operates reliably between -20°C minimum and 60°C maximum operating temperatures.
Slotted blade contacts compatible with M10 screw fixing and NH fuse bases.
Type aR operating class for partial-range semiconductor protection.
Compact design with height 63.5 mm and width 52 mm to fit standard setups.
High rupture capacity ensures effective overload and short circuit protection.

Product Description

Siemens 3NE3230-0B NH Fuse is a high quality electrical fuse designed for semiconductor and cable protection in industrial, electrical, automation, and manufacturing applications. Rated at 315A current and 1kV voltage, this NH1 size fuse provides dependable overload and short circuit protection. Its high rupture capacity enhances safety by reliably interrupting fault currents and protecting power rails, cables, and wires.

The fuse features slotted blade contacts suitable for installation in NH fuse bases or load-break switches, secured with M10 screw fixing. The operating class aR indicates its suitability for partial-range semiconductor protection, ideal for high performance electronic equipment and circuits.

Key dimensions of the fuse include 73 mm length, 110 mm fixing centres, 135 mm overall length, 63.5 mm height, and 52 mm width for compatibility with standard NH1 fuse holders. It operates within a temperature range of -20°C to 60°C, making it reliable in various industrial environments.

Manufactured in Greece to IEC 60269-2 standards, the Siemens 3NE3 Series fuse ensures durability and safety compliance. This component is essential for electrical system protection in commercial, industrial, manufacturing, and automation setups requiring high fault current interrupting capacity.

Rated current of 315A for secure electrical load management. 1kV voltage rating for medium voltage systems. High rupture capacity enhances fault clearing ability. Designed for semiconductor protection (Class aR). Slotted blades for secure connection in fuse holders.

Operating temperature range from -20°C to 60°C. Compact physical dimensions ensuring easy integration. Compliance with IEC 60269-2 improves safety standards. Manufactured in Greece ensuring quality and reliability. Suitable for industrial, electrical, manufacturing, and automation applications.

Find this Siemens NH fuse and other electrical protection components at EnvMart for your circuit breaker and fuse requirements.
