Patlite LR6 Series Amber Blue Clear White Red Green Signal Tower Buzzer 24V DC Pole Mount LR6-102PJNW-G
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Patlite |
| Height | 429mm |
| Model | LR6-102PJNW-G |
| IP Rating | IP65 |
| Mount Type | Pole Mount |
| Bulb Type | LED |
| Series | LR6 |
| Maximum Operating Temperature | 50°C |
| Current Type | DC |
| Current consumption | 250mA |
| Minimum Operating Temperature | -20°C |
| Base Diameter | 60mm |
| Terminal type | Cable |
| Lens Colour | Amber, Blue, Clear, White, Red, Green |
| Standards/Approvals | RoHS (EN 50581), UL Component (File No.E215660), CSA-C22.2 No. 14, FCC Part 15 Subpart B Class A, UL 508, KC (KN 61000-6-4,KN 61000-6-2), EMC (EN 61000-6-4,EN 61000-6-2) |
| Maximum Supply Voltage | 24V |
| Housing Colour | Off-White |
| Light Effect | Steady |
| Minimum Sound Level | 85dB |
| Sounder Type | Buzzer |
| Sound Level at 1m | 90dB |
| Maximum Sound Level | 90dB |
| Number of Light Elements | 1 |
| Connection Cable Length | 1m |
| Multifunction | Yes, Yes |
Key Features
- Features a modular "Twist and Lock" system for easy customization of LED and sound modules.
- Equipped with a buzzer type sounder delivering 90dB omni-directional sound at 1m distance.
- Constructed with an off-white housing color and steady light effect LED bulb.
- Designed for operating temperatures from -20°C to 50°C with IP65 rating for dust and water protection.
- Includes a 1 meter connection cable for straightforward installation and pole mount base.
- Complies with RoHS, UL, CSA, FCC, KC, and EMC standards ensuring reliability and safety.
- Sound consumption is 250mA current at 24V DC supply voltage.
- Compact design with height of 429mm and base diameter of 60mm.
Product Description
Patlite LR6-102PJNW-G Signal Tower Buzzer designed for industrial automation signalling applications operating at 24V DC. This single-light tower features an LED bulb with selectable lens colors including Amber, Blue, Clear, White, Red, and Green, delivering clear and bright steady light for effective visual signalling.
The device incorporates a buzzer sounder type producing omni-directional sound at a maximum of 90dB at 1 meter, suitable for audible alerts in noisy environments. It operates reliably within a temperature range of -20°C to 50°C and is rated IP65, ensuring protection against dust ingress and water jets, making it suitable for harsh industrial settings.
This model utilizes a modular "Twist and Lock" design, simplifying the customization and reconfiguration of LED and sound modules, to fit varying signalling requirements. The off-white housing is robustly constructed with a height of 429mm and base diameter of 60mm, designed for pole mounting with a 1-meter connection cable for easy installation.
It complies with multiple international standards including RoHS (EN 50581), UL Component (File No.E215660), CSA-C22.2 No.14, FCC Part 15 Subpart B Class A, UL 508, KC (KN 61000-6-4, KN 61000-6-2), and EMC (EN 61000-6-4, EN 61000-6-2), ensuring excellent quality and regulatory adherence.
This Signal Tower buzzer is ideal for use in industrial automation, manufacturing facilities, water treatment plants, HVAC systems, and other commercial environments requiring reliable visual and audible alerts. The robust design supports extended service life and consistent performance, even in demanding applications.
The product is made in Japan, reflecting high manufacturing standards and quality assurance. The unit's power supply is DC 24V with a current consumption of 250mA, optimized for efficient operation.
Modular "Twist and Lock" system enabling easy customization and maintenance. Omni-directional buzzer with 90dB maximum sound level suitable for noisy industrial settings. Highly visible steady LED lights with multi-color lens options: Amber, Blue, Clear, White, Red, and Green.
Durable off-white housing rated IP65 for dust and water resistance. Operating temperature range from -20°C to 50°C for versatile industrial use. Complies with international safety and electromagnetic compatibility standards.
1 meter connection cable and pole mounting for flexible installation. Compact design with 429mm height and 60mm base diameter. Browse the Electronics & Electricals category at EnvMart for more automation signalling and LED lighting products tailored to industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum sound level of this model is 90dB at a distance of 1 meter.
It operates reliably within a temperature range of -20°C to 50°C.
This unit is designed for pole mounting.
The LED bulb offers selectable lens colors including Amber, Blue, Clear, White, Red, and Green.
The current consumption is 250mA when operating at 24V DC.
It has an IP65 rating, providing protection against dust and water.
The signal tower comes with a 1-meter connection cable for installation.
It complies with multiple standards including RoHS, UL, CSA, FCC, KC, and EMC.
This model features a buzzer sounder type, which produces omni-directional sound.
The height of this model is 429mm, and the base diameter is 60mm.
The LED provides a steady light effect for visual signalling.
This product is made in Japan, reflecting high manufacturing standards.
