Amphenol Limited MIL Spec Circular Connector 41 Contacts Copper Alloy Straight 700V 7.5A Cable Mount Bayonet 62GB-16F20-41SN
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Voltage | 700V |
| Brand | Amphenol Limited |
| Orientation | Straight |
| Current | 7.5A |
| Model | 62GB-16F20-41SN |
| Temperature Operating Range | -55°C to 125°C |
| Mount Type | Cable |
| Contact Material | Copper Alloy |
| Series | 62GB |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 41 |
| Contact Gender | Female |
| Connector Gender | Male |
| Shell Size | 20 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Standard |
| Wire gauges and current carrying capabilities | Upto 45A and size 24 to 8 AWG wires |
Key Features
- This connector features a copper alloy body with gold-plated female contacts.
- Operating voltage is rated at 700V and current capacity is 7.5A.
- The shell size is standard 20 with a straight orientation for secure connections.
- Temperature range from -55°C to 125°C ensures reliable operation in extreme environments.
- Meets military standard MIL-DTL-26482 and offers strain relief for cable durability.
- Termination type is crimp suitable for high performance electrical connections.
- Connector series 62GB incorporates keyway for reduced mismating risks.
Product Description
Amphenol Limited 62GB-16F20-41SN Mil Spec Circular Connector features a rugged copper alloy body with gold-plated female contacts, providing reliable electrical performance in military and industrial environments. This straight orientation connector is designed for cable mounting applications and operates safely up to 700 volts and 7.5 amps. The connector shell size 20 complies with MIL-DTL-26482 military standards, including a resilient neoprene insulator and rear sealing grommet ensuring a liquid-tight assembly.
The operating temperature range from -55°C to 125°C allows use in extreme conditions. Its bayonet mating type and keyway orientation reduce mismating in complex electrical setups. Suitable wire gauges range from 24 to 8 AWG, capable of carrying currents up to 45A with other series variants.
This connector's crimp termination and strain relief features provide secure mechanical and electrical integrity, making it ideal for demanding industrial, military, and aerospace electronics applications requiring ruggedized, high-reliability connections.
This connector offers gold-plated female contacts for enhanced conductivity and corrosion resistance. Operating voltage capacity is 700V with a current rating of 7.5A for efficient power handling. Shell size 20 ensures standard fitment and compatibility in MIL spec systems.
Compliance with MIL-DTL-26482 ensures rigorous military-grade reliability and durability. Temperature tolerance from -55°C to 125°C permits use in harsh outdoor and industrial conditions. Bayonet mating provides fast, secure coupling with reliable locking.
Strain relief and crimp termination enhance long-term connection stability and cable protection.
This connector is manufactured in the United Kingdom, reflecting high-quality engineering standards. It is suitable for Electronics, Electrical, Defence, Aerospace, and Industrial automation sectors requiring robust circular connectors with MIL specification compliance. Explore more high-quality MIL Spec connectors and related components in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this connector is 700V.
This model has a current capacity of 7.5A.
The operating temperature range is from -55°C to 125°C.
This connector uses crimp termination for secure electrical connections.
This connector features 41 female contacts.
The connector has a copper alloy body with gold-plated female contacts.
The shell size of this connector is standard size 20.
This connector utilizes a bayonet mating type for secure connections.
It complies with the military standard MIL-DTL-26482.
This connector supports wire gauges from 24 to 8 AWG.
This connector is manufactured in the United Kingdom.
It is suitable for electronics, electrical, defense, aerospace, and industrial automation sectors.
