Rose Aluminium Standard Series Die Cast Aluminium Enclosure, IP66, IK09, 230 mm x 230 mm x 100 mm 01231011

Rose 01231011 Aluminium Standard Series Die Cast Aluminium Enclosure is engineered from high-quality die cast aluminium providing robust protection for electrical and industrial control equipment. This enclosure offers IP66 degree of protection, ensuring complete dust ingress prevention and resistance to powerful water jets, making it highly suitable for industrial, chemical laboratory, aviation, process, and packaging industry applications.

The enclosure features an IK09 rating for mechanical impact resistance, supporting safe use in demanding environments. Its polyurethane gasket maintains an effective seal against dust and moisture, enhancing the safety of internal electrical components. Designed with a compact form factor measuring 230 mm in height and length, and 100 mm in width, it fits efficiently in confined spaces.

Weighing only 1.8 kg, the enclosure minimizes load on mounting surfaces and allows versatile mounting options including DIN rail and mounting plates. It is certified for hazardous conditions including maritime applications and UL standards, meeting industrial safety requirements. The broad operational temperature range from -40°C to +90°C ensures dependable performance under various environmental conditions.

The grey lid and enclosure uphold a professional aesthetic ideal for electrical control panels and industrial setups. Its unshielded design ensures easy access while safeguarding against unauthorized tampering with secure lid screws.

Applications include chemical laboratories, aviation industry, process, and packaging sectors requiring reliable, durable, and safe electrical enclosures. Constructed from robust die cast aluminium for durability and corrosion resistance.

Meets IP66 rating for dust tightness and protection against powerful water jets. Features IK09 impact rating for high resistance to mechanical impacts. Equipped with polyurethane gasket for enhanced sealing against dust and moisture.

Lightweight design at 1.8 kg reduces strain on mounting surfaces. Suitable for installation on DIN rail or mounting plates in industrial environments. Certified for hazardous areas including maritime and UL standards compliance.

Designed to operate reliably within a temperature range of -40°C to +90°C. Grey-colored lid and enclosure for professional and clean appearance. Explore EnvMart’s selection of Electrical Enclosures for industrial and commercial applications, including aluminium and general purpose enclosures.
