Rose Aluform Series Grey Grey Lid Die Cast Aluminium Enclosure IP66 IK09 120 mm x 120 mm x 120 mm IP66

Free Delivery in India | Lowest Global Shipping Charges

Rose Aluform Series Grey Grey Lid Die Cast Aluminium Enclosure IP66 IK09 120 mm x 120 mm x 120 mm IP66

Name: Rose Aluform Series Grey Grey Lid Die Cast Aluminium Enclosure IP66 IK09 120 mm x 120 mm x 120 mm IP66
Brand: Rose
SKU: 184537
Price: 99.63 USD
Availability: InStock



Category General Purpose Enclosures Brand Rose Condition New

Specifications

Country of Origin	Germany
Brand	Rose
Body Material	Die Cast Aluminium
Model	IP66
IP Rating	IP66
Gross Weight	880g
Series	Aluform
External Width	120mm
External Height	120mm
Shielding	Unshielded
Hazardous Area Certification	Maritime, UL
Standards/Approvals	RoHS Compliant
External Length	120mm
Lid Colour	Grey
IK Rating	IK09
Gasket Material	Polyurethane
Number of Knockouts	0

Key Features

Constructed from die-cast aluminium for impact and corrosion resistance.
Compact dimensions of 120 mm height, width, and length fit small spaces.
Features a durable polyurethane gasket seal to prevent contaminant ingress.
Equipped with captive stainless steel lid screws to prevent unauthorized access.
Suitable for DIN rail mounting, enabling tool-free installation.
Designed to operate reliably between -60°C and +130°C.
Four earthing screws at the base ensure static electricity deflection for electrical safety.
Compliant with RoHS standards and carries Maritime and UL hazardous area certifications.

Product Description

Rose IP66 Die Cast Aluminium Enclosure, model IP66, offers a high degree of protection with an IP66 rating against dust and powerful water jets, complemented by IK09 mechanical impact resistance rating. Its die-cast aluminium body guarantees durability in harsh environmental conditions, measuring 120 mm in height, width, and length with a 3 mm thick wall for added strength.

The enclosure includes a robust polyurethane gasket seal that effectively prevents the entry of dust, moisture, and other contaminants, while captive stainless steel screws on the lid secure the enclosure against unauthorized tampering. Designed for convenient DIN rail mounting, this enclosure supports quick and tool-free installation.

Operating in a broad temperature range from -60°C to +130°C, it is suitable for demanding industrial applications including food and beverage production, cable management, oil and gas, IT centers, and manufacturing industries. The base features four earthing screws to safely deflect static electricity, protecting sensitive electrical and electronic equipment housed inside.

Certified to meet RoHS standards and hazardous area certifications such as Maritime and UL, this enclosure is engineered for reliability and safety. Its grey lid complements the grey body, providing a consistent industrial aesthetic.

Constructed from die-cast aluminium for impact and corrosion resistance. Compact 120 mm x 120 mm x 120 mm dimensions fit into compact installations. Polyurethane gasket ensures dust-tight and watertight sealing. Captive stainless steel screws enhance security and prevent loss.

Tool-free DIN rail mounting simplifies assembly and maintenance. Wide operating temperature range from -60°C to +130°C. Four earthing screws provide effective static discharge protection. Complies with RoHS standards; hazardous area certifications include Maritime and UL.

This enclosure is ideal for industrial, commercial, and outdoor applications requiring robust protection of electronics and equipment. Discover more solutions in the General Purpose Enclosures category at EnvMart.
