onsemi MOSFET Gate Driver 2 Output 1.5 A 8-Pin SOIC 18V MC33151DG

Free Delivery in India | Lowest Global Shipping Charges

onsemi MOSFET Gate Driver 2 Output 1.5 A 8-Pin SOIC 18V MC33151DG

Name: onsemi MOSFET Gate Driver 2 Output 1.5 A 8-Pin SOIC 18V MC33151DG
Brand: onsemi
SKU: 149451
Price: 1.41 USD
Availability: InStock



Category MOSFET Gate Driver Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	5mm
Model	MC33151DG
Width	4mm
Mount Type	Surface
Series	MC33151
Output Current	1.5A
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Number of outputs	2
Rise Time	14ns
Pin Count	8
Minimum Supply Voltage	18V
Number of Drivers	2
Fall Time	16ns
Driver Type	MOSFET

Key Features

The device supports surface mount technology with a compact SOIC package.
It provides a rise time of 14 nanoseconds and fall time of 16 nanoseconds for effective switching.
Operating temperature ranges from -40°C to 85°C, suitable for industrial applications.
MOSFET and IGBT drive capability makes it ideal for power management circuits.
The product's physical dimensions approximate 5 mm in length, 4 mm in width, and 1.5 mm in height.
This device does not include automotive standard certification.
Designed for use in low-side, high-side, and half-bridge MOSFET/IGBT configurations.

Product Description

onsemi MC33151DG is a MOSFET Gate Driver designed for driving power MOSFETs and IGBTs in various power management applications. This device includes two outputs capable of 1.5 A continuous current, packaged in an 8-pin SOIC, surface-mount package operating at a nominal supply voltage of 18V.

The build quality and surface mount configuration make it ideal for dense PCB layouts in industrial and commercial electronic circuits. With fast rise and fall times of 14 ns and 16 ns respectively, it allows for efficient power switching, minimizing transition losses.

The MC33151DG operates reliably within a temperature range from -40°C to 85°C, allowing use in demanding thermal environments. It is suited for low-side, high-side, and half-bridge driver circuits commonly found in motor control, power supplies, and industrial automation.

Its physical dimensions of 5 mm length, 4 mm width, and 1.5 mm height contribute to compact design integration. Although it does not carry automotive standard certification, it remains suitable for a wide range of commercial and industrial uses.

The device is part of onsemi's MC33151 series and meets essential power driver specifications without special approvals or automotive classifications. Applications span areas such as electronics manufacturing, power management, and embedded system design.

The device supports surface mount technology with a compact SOIC package. It provides a rise time of 14 nanoseconds and fall time of 16 nanoseconds for effective switching. Operating temperature ranges from -40°C to 85°C, suitable for industrial applications.

MOSFET and IGBT drive capability makes it ideal for power management circuits. The product's physical dimensions approximate 5 mm in length, 4 mm in width, and 1.5 mm in height. This device does not include automotive standard certification.

Designed for use in low-side, high-side, and half-bridge MOSFET/IGBT configurations. Discover the extensive range of power management ICs and semiconductor components available at EnvMart for enhanced engineering solutions.
