Texas Instruments Fixed Series Voltage Reference ±0.05 % Accuracy 2.05V 8-Pin SOIC REF5020AID

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Fixed Series Voltage Reference ±0.05 % Accuracy 2.05V 8-Pin SOIC REF5020AID

Name: Texas Instruments Fixed Series Voltage Reference ±0.05 % Accuracy 2.05V 8-Pin SOIC REF5020AID
Brand: Texas Instruments
SKU: 160414



Category Voltage References Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1.5mm
Length	5mm
Model	REF5020AID
Mount Type	Surface
Output type	Fixed
Series	REF5020
Temperature Coefficient	3 ppm/°C
Output Current	10mA
Topology	Series
Maximum Operating Temperature	125°C
Package Type	SOIC
Load Regulation	50 ppm/mA
Minimum Operating Temperature	-40°C
Reference Type	Fixed
Maximum Input Voltage	18V
Line Regulation	1 ppm/V
Minimum Input Voltage	2.25V
Pin Count	8
Reference Voltage	2.05V
Initial Accuracy	±0.05 %

Key Features

Provides a precise fixed reference voltage for power management applications.
Features an initial accuracy of ±0.05 % ensuring reliable performance.
Operates over a temperature range from -40°C to 125°C.
Outputs a fixed voltage of 2.05V suitable for accurate voltage regulation.
Supports a maximum input voltage of 18V with a load current of up to 10mA.
Compact 8-pin SOIC surface-mount package with 5mm length and 1.5mm height.
Low temperature coefficient of 3 ppm/°C for stability in varying conditions.
Line regulation of 1 ppm/V and load regulation of 50 ppm/mA for stable output.

Product Description

Texas Instruments REF5020AID is a fixed series voltage reference component designed for precise voltage management and regulation in electronic circuits. It delivers a stable fixed output voltage of 2.05V with excellent initial accuracy of ±0.05 %, making it ideal for applications in power management, industrial instrumentation, and instrumentation amplifiers.

This voltage reference is housed in an 8-pin SOIC surface-mount package that measures 5mm in length and 1.5mm in height, allowing for compact PCB designs. The device withstands operating temperatures ranging from -40°C to 125°C, making it suitable for harsh industrial environments.

With a low temperature coefficient of 3 ppm/°C, the REF5020AID maintains stability over temperature variations. Its line regulation of 1 ppm/V and load regulation of 50 ppm/mA ensure consistent voltage output even under varying input voltage and load conditions. Maximum input voltage supported is 18V, with a maximum output current of 10mA, suitable for powering low-current circuitry.

This component does not carry specific automotive standards but is widely used in laboratory electronics, industrial power management, and commercial electronic products requiring precision voltage references. The fixed output type simplifies circuit design where a stable reference voltage is crucial.

Provides a precise fixed reference voltage for power management applications. Features an initial accuracy of ±0.05 % ensuring reliable performance. Operates over a temperature range from -40°C to 125°C. Outputs a fixed voltage of 2.05V suitable for accurate voltage regulation.

Supports a maximum input voltage of 18V with a load current of up to 10mA. Compact 8-pin SOIC surface-mount package with 5mm length and 1.5mm height. Low temperature coefficient of 3 ppm/°C for stability in varying conditions.

Line regulation of 1 ppm/V and load regulation of 50 ppm/mA for stable output. Designed without specific automotive standards compliance.

Explore more precision power management components like the Texas Instruments REF5020AID in the Voltage References category at EnvMart for professional and industrial applications.
