HARTING D-Sub 9 Way Right Angle Through Hole Connector with 4 to 40 UNC Screw Lock Female Contacts 6.5A 09681535613

Free Delivery in India | Lowest Global Shipping Charges

HARTING D-Sub 9 Way Right Angle Through Hole Connector with 4 to 40 UNC Screw Lock Female Contacts 6.5A 09681535613

Name: HARTING D-Sub 9 Way Right Angle Through Hole Connector with 4 to 40 UNC Screw Lock Female Contacts 6.5A 09681535613
Brand: HARTING
SKU: 146214



Category Connectors Brand HARTING Condition New

Specifications

Country of Origin	China
Brand	HARTING
Orientation	Right Angle
Current	6.5A
Mount Type	Through Hole
Housing Material	Fibreglass Reinforced Thermoplastic
Contact Material	Copper Alloy
Series	D-Sub
Mounting Hardware	4 to 40 UNC Screw Lock
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Contact Plating	Steel
Number of Contacts	9
Contact Gender	Female
Connector Gender	Female
Connector Type D	D-Sub

Key Features

Features a robust metal shell for enhanced durability and protection.
Rated for 6.5 amperes of current, suitable for various electronic applications.
Right angle orientation allows versatile PCB mounting configurations.
Through hole mount type ensures solid mechanical connection to the PCB.
Equipped with 4 to 40 UNC screw lock mounting hardware for secure panel fixing.
Contact material is copper alloy with steel plating ensuring good conductivity and corrosion resistance.
Housing constructed from fibreglass reinforced thermoplastic for stability at high temperatures.
Typical operating temperature range from -55°C to 125°C ensures reliable function in harsh environments.

Product Description

HARTING 09681535613 D-Sub 9 Way Right Angle Through Hole Connector delivers reliable and durable performance in electronic and power connector applications. This female D-Sub connector contains 9 copper alloy contacts, each rated at 6.5A current, suitable for medium power signal transmission.

The connector's right angle orientation with through hole mounting allows secure mechanical and electrical connections on printed circuit boards, optimized for industrial, computing, and communication equipment assembly. The metal shell construction improves shielding and mechanical robustness, while the fibreglass reinforced thermoplastic housing ensures the connector withstands high temperatures and mechanical stress.

This connector is fitted with 4 to 40 UNC screw lock hardware, providing secure panel mounting and alignment during installation. The solder termination type guarantees a strong, stable connection ideal for manufacturing environments requiring reliability and longevity. The design complies with U.S. footprint standards and includes an extra grounding pin for enhanced electrical safety and noise reduction.

Robust metal shell enhances durability and electromagnetic shielding. 6.5A rated copper alloy contacts ensure efficient current handling. Right angle design facilitates PCB mounting flexibility. Through hole mounting type provides mechanical strength.

4 to 40 UNC screw lock guarantees secure panel mounting. Fibreglass reinforced thermoplastic housing supports wide temperature ranges. Solder termination type assures reliable electrical contacts. Extra grounding pin included for improved safety and noise reduction.

Complies with U.S. footprint for compatibility with standard equipment.

Typical industrial applications include electronic equipment assembly, power supply connections, data communication interfaces, and ruggedized equipment installations in harsh environments. This HARTING D-Sub connector exemplifies quality performance for demanding manufacturing and maintenance operations.
