SMC Pneumatic Guided Cylinder 40mm Bore, CQM Series, 25 mm Stroke, Double Acting, Through Hole Mount CDQMB40-25
Specifications
| Country of Origin | India |
|---|---|
| Brand | SMC |
| Body Material | Aluminium Alloy |
| Maximum Operating Pressure | 1 Mpa |
| Height | 52mm |
| Length | 81.5mm |
| Model | CDQMB40-25 |
| Gross Weight | 370g |
| Width | 66mm |
| Mount Type | Through Hole |
| Series | CQM |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -10°C |
| Stroke Length | 25mm |
| Bore Diameter | 40mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Cushioning Type | Rubber |
| Guide Type | Slide Bearing |
Key Features
- The cylinder features a durable aluminium alloy body with hard anodised finish for corrosion resistance.
- It provides through hole mounting and slide bearing guide type for stable operation.
- Designed for double acting action with a 25 mm stroke length and 40 mm bore diameter.
- Operates safely within a maximum pressure of 1 Mpa and speeds up to 500mm/s.
- Equipped with rubber cushioning to reduce impact and noise during operation.
- Functional in temperature ranges from -10°C to 70°C, suitable for various industrial environments.
- Single rod type offers direct load accommodation with non-rotatable piston design.
- Compact dimensions and light weight of 370 grams optimise handling and installation.
Product Description
SMC CDQMB40-25 Pneumatic Guided Cylinder is part of the CQM series, featuring a 40mm bore diameter and 25mm stroke length. It is a double acting cylinder designed with a hard anodised aluminium alloy body that offers durability and corrosion resistance for industrial fluid power systems.
The cylinder includes a slide bearing guide type and a single rod with non-rotatable piston, providing reliable lateral load resistance exceeding that of standard CQ series cylinders. Its through hole mount facilitates secure and flexible installation.
Operating pressure is rated up to 1 Mpa with a maximum piston speed of 500mm/s. Rubber cushioning effectively minimizes impact noise and wear, enhancing operational lifespan. The unit is engineered to work in ambient temperatures ranging from -10°C to 70°C, suitable for diverse industrial environments.
This pneumatic guided cylinder is ideally used in factory automation, manufacturing equipment, pneumatic actuation systems, and other applications requiring precise, guided linear motion and robust load handling capabilities.
The cylinder features a durable aluminium alloy body with hard anodised finish for corrosion resistance. It provides through hole mounting and slide bearing guide type for stable operation. Designed for double acting action with a 25 mm stroke length and 40 mm bore diameter.
Operates safely within a maximum pressure of 1 Mpa and speeds up to 500mm/s. Equipped with rubber cushioning to reduce impact and noise during operation. Functional in temperature ranges from -10°C to 70°C, suitable for various industrial environments.
Single rod type offers direct load accommodation with non-rotatable piston design. Compact dimensions and light weight of 370 grams optimise handling and installation. Applicable in pneumatic cylinders & actuators relevant to manufacturing, automation, and material handling.
EnvMart offers this SMC Cylinder as a robust solution for Pneumatic Guided Cylinder needs in industrial, manufacturing, and automation sectors.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 1 Mpa.
The cylinder has a height of 52 mm, a length of 81.5 mm, and a width of 66 mm.
It features a stroke length of 25 mm and a bore diameter of 40 mm.
This model utilizes a through hole mounting type for secure installation.
It operates effectively within a temperature range of -10°C to 70°C.
This cylinder is equipped with rubber cushioning to minimize impact and noise during operation.
The gross weight of this unit is 370 grams.
It is designed for double acting action.
The cylinder features a slide bearing guide type for stable operation.
The country of origin for this cylinder is India.
It is suitable for factory automation, manufacturing equipment, and pneumatic actuation systems.
The maximum piston speed is rated at 500 mm/s.
