SMC Pneumatic Guided Cylinder, 16mm Bore, CQM Series, 20 mm Stroke, Double Acting, Through Hole Mount CDQMB16-20

Free Delivery in India | Lowest Global Shipping Charges

SMC Pneumatic Guided Cylinder, 16mm Bore, CQM Series, 20 mm Stroke, Double Acting, Through Hole Mount CDQMB16-20



Category Pneumatic Guided Cylinder Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Body Material	Aluminium Alloy
Maximum Operating Pressure	1 Mpa
Height	29mm
Length	51.5mm
Model	CDQMB16-20
Gross Weight	87g
Width	29mm
Mount Type	Through Hole
Series	CQM
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-10°C
Stroke Length	20mm
Bore Diameter	16mm
Rod Type	Single
Action Type	Double Acting
Cushioning Type	Rubber
Guide Type	Slide Bearing

Key Features

The cylinder features a robust aluminium alloy hard anodized body providing excellent durability.
Uses a slide bearing guide type to ensure smooth operation under load.
Equipped with rubber cushioning type for effective shock absorption.
Operates reliably within a temperature range from -10°C to 70°C.
Suitable for industrial applications requiring compact guided cylinders with a maximum operating pressure of 1 MPa.
Double acting design offers forward and return stroke control.
Mount type is through hole allowing versatile installation options.
Compact dimensions with height and width of 29mm and length of 51.5mm enhance integration flexibility.

Product Description

SMC CDQMB16-20 Pneumatic Guided Cylinder from the CQM Series is a precision-engineered 16mm bore compact cylinder designed for pneumatic actuation requiring high lateral load resistance and accurate guidance. Its aluminium alloy hard anodized body delivers exceptional corrosion resistance and strength for industrial environments.

This double acting pneumatic guided cylinder features a through hole mount for secure and flexible installation in fluid power automation systems. The inclusion of a slide bearing guide type improves the piston rod's lateral stiffness, extending cylinder life longevity and maintaining performance under side loads.

The cylinder is cushioned with rubber to reduce mechanical shock and noise at stroke ends. It operates effectively in temperatures ranging from -10°C to 70°C and withstands maximum operating pressures up to 1 MPa, making it suitable for various manufacturing, assembly, packaging, and material handling applications.

Measuring 29mm in height and width, 51.5mm in length with a 20mm stroke length, this lightweight 87-gram unit supports fast piston speeds up to 500 mm/s, ensuring responsiveness in automated pneumatic systems. Its non-rotatable guide rod design enhances stability during operation.

The cylinder's body is made from durable aluminium alloy with hard anodizing. Guide type is slide bearing to manage lateral forces efficiently. Rubber cushioning type minimizes impact and noise at stroke ends. Maximum operating pressure is 1 MPa for reliable pneumatic control.

Operating temperature ranges between -10°C and 70°C for versatile industrial use. Mounting is via through hole facilitating flexible installation configurations. Stroke length is 20 mm allowing precise motion control. Compact dimensions and light weight allow easy integration into machinery.

This SMC pneumatic guided cylinder is ideal for industrial, manufacturing, assembly line automation, material handling, and packaging equipment that require compact, durable, and precise pneumatic actuation components. Its advanced design and robust construction ensure long service life and consistent operation in demanding commercial and industrial pneumatic systems.
