SMC Pneumatic Guided Cylinder 32mm Bore Double Acting Aluminium Alloy Body CDQMB32-20

SMC CDQMB32-20 Pneumatic Guided Cylinder with a 32mm bore diameter features a robust aluminium alloy body designed for enhanced durability in industrial environments. This model belongs to the CQM series and employs a double acting mechanism allowing precise and reliable piston movement, ideal for applications requiring effective push and pull forces in pneumatic systems.

The cylinder integrates rubber cushioning to reduce impact noise and vibration, improving operational safety and longevity. It supports a maximum operating pressure of 1 Mpa and a maximum piston speed of 500 mm/s, enabling it to handle demanding pneumatic tasks efficiently.

Designed with slide bearing guides, this cylinder offers stable and precise guidance along the piston rod, which is single type. It is mountable via a through hole type mount, facilitating secure installation in various machinery setups. The compact size with dimensions 70 mm length, 58.5 mm width, and 45 mm height makes it suitable for spaces with limited room.

This product is engineered to operate within a temperature range of -10°C to 70°C, ensuring reliable performance under varying environmental conditions. The cylinder is non-rotatable, featuring a hard anodized aluminium body that enhances corrosion resistance and wear durability.

With a gross weight of 250 grams and manufactured in China, the CDQMB32-20 is an optimal choice for industrial, manufacturing, automation, and fluid power applications requiring precise, guided linear motion. It complies with standard pneumatic cylinder requirements but has no additional certifications reported.

Constructed with a durable aluminium alloy body for longevity. Features a 32mm bore diameter suitable for compact operations. Double acting functionality provides efficient piston control. Equipped with rubber cushioning for smooth operation and noise reduction.

Maximum operating pressure of 1 Mpa supports versatile industrial applications. Slide bearing guide type ensures stable and precise guidance. Operating temperature range from -10°C to 70°C adapts to varied environments. Compact dimensions with length 70mm and stroke length 20mm optimize installation space.

Lightweight design at 250g enhances ease of handling and installation. This SMC Pneumatic Guided Cylinder is suitable for integration in pneumatic systems across industrial plants, manufacturing automation, and fluid power sectors.
