Microchip 8 bit AVR ATTINY841 Microcontroller 16 MHz 8kB FLASH 14-Pin SOIC ATTINY841-SSU

Microchip ATTINY841-SSU is an 8-bit AVR microcontroller optimized for applications requiring compact size, low power consumption, and high integration. It features a maximum clock frequency of 16 MHz, 8kB of FLASH program memory, and 512 bits of RAM, supporting efficient and fast code execution in embedded systems.

This device is housed in a space-saving 14-Pin SOIC package, designed for surface mount technology, making it ideal for modern PCB assembly processes. With a supply voltage range from 1.7V to 5.5V, it accommodates a variety of power sources including battery-powered devices.

The microcontroller includes 12 programmable input/output pins which allow interfacing with various external components and sensors. Additionally, it provides 12 ADC channels with 10-bit resolution enabling precise analog-to-digital conversion, useful in sensor and measurement applications. Two analogue comparators and two timers offer enhanced control for timing and signal comparison functionalities.

The compact physical dimensions (8.74mm length, 3.99mm width, and 1.5mm height) coupled with an operating temperature range of -40°C to +85°C make this microcontroller suitable for use in industrial, automotive, consumer electronics, and HVAC control systems where reliability and durability are critical.

This component uses the RISC instruction set architecture to ensure high efficiency and speed while maintaining low power consumption. The program memory is of FLASH type, allowing for reprogramming and development flexibility.

Manufactured in Taiwan, Province Of China, the ATTINY841-SSU adheres to industry standards though it does not carry specific approvals. It is an ideal choice for engineers designing compact and efficient embedded applications.

Utilizes AVR architecture for efficient 8-bit processing. Operates at voltage range of 1.7V to 5.5V for flexible power requirements. Provides 12 programmable input/output pins for versatile interfacing. Equipped with 12 ADC channels of 10-bit resolution for analog signal conversion.

Features 2 analogue comparators for precise signal comparison tasks. Includes 2 timers supporting advanced timing functions. Compact dimensions of 8.74mm length, 3.99mm width, and 1.5mm height suitable for space-constrained designs.

Wide operating temperature range from -40°C to +85°C for industrial reliability. Flash memory program type offers efficient and reusable code storage. Designed for surface mount (SOIC) applications improving assembly efficiency.
