WEG Thermal Overload Relay 10A F.L.C, 1 NO/1 NC, 7-10A Adjustable Current, 1.4W Power Rating RW17



Category Overload Relay Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Length	71.5mm
Model	RW17
Depth	82.5mm
IP Rating	IP10, IP20
Width	45mm
Mount Type	DIN Rail
Series	RW17
Power Rating	1.4W
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Supply Voltage	1, 50kV
Contact Voltage	690V ac
Reset Method	Automatic & Manual
Normal State Configuration	1 NO/1 NC
Relay Contact Current	10, 7A
Number of Auxiliary Contacts	2
Pole and Throw Configuration	3
FLC Motor Rating	10A
Adjustable Current Range	7 → 10 A

Key Features

Features 1 normally open and 1 normally closed contact configuration.
Power rating of 1.4 watts ensures efficient operation.
DIN rail mount type for easy installation in control panels.
Equipped with screw terminal type for secure wiring connections.
Automatic and manual reset methods available for flexible use.
IP10 and IP20 ratings provide protection against dust and contact.
Operates reliably between -25°C to 60°C temperature range.
Contact voltage rating up to 690V AC for industrial applications.

Product Description

WEG RW17 Thermal Overload Relay is designed for industrial motor protection applications with a full load current rating (FLC) of 10A and an adjustable current range from 7 to 10 amperes. The device includes 1 normally open (NO) and 1 normally closed (NC) contact which allows versatile control and protection configurations. It has a power rating of 1.4 watts and houses 2 auxiliary contacts for enhanced operational feedback.

This relay is equipped with screw terminals ensuring secure and reliable wiring, and it mounts easily on DIN rails commonly used in control panels. The reset method can be selected as automatic or manual, offering flexibility depending on the application's requirement.

With an IP10 and IP20 protection rating, the relay is safeguarded against physical contact and dust ingress, making it suitable for a variety of industrial environments. It operates efficiently within a temperature range from -25°C to 60°C, ensuring durability even in varying conditions.

Rated for a contact voltage of up to 690V AC, this thermal overload relay complies with IEC standards including IEC 60947-4-1 and IEC 60947-1, ensuring robust performance and safety. The compact dimensions (45mm width, 71.5mm length, 82.5mm depth) make it suitable for tight installation spaces.

Its tripping class is 10 and it features phase failure sensitivity with selectable reset modes. Manufactured in Brazil, it aligns with energy efficiency directives like Directive 2009/125/EC and related IEC standards, making it an ideal choice for industrial automation, control systems, manufacturing processes, and electrical panels.

Features 1 normally open and 1 normally closed contact configuration. Power rating of 1.4 watts ensures efficient operation. DIN rail mount type for easy installation in control panels. Equipped with screw terminal type for secure wiring connections.

Automatic and manual reset methods available for flexible use. IP10 and IP20 ratings provide protection against dust and contact. Operates reliably between -25°C to 60°C temperature range. Contact voltage rating up to 690V AC for industrial applications.

Compact dimensions: Width 45mm, Length 71.5mm, Depth 82.5mm. Includes 2 auxiliary contacts supporting control and signalling functions.

This thermal overload relay is suitable for use in industrial, manufacturing, electrical, and automation systems demanding reliable motor protection. Explore more quality Overload Relays and WEG products on EnvMart for optimized control solutions.
