RS PRO 8-Pole DIN Rail Isolator Switch IP65 25A 11 kW IP65
Specifications
| Country of Origin | India |
|---|---|
| Brand | RS PRO |
| Length | 280mm |
| Model | IP65 |
| Depth | 130mm |
| IP Rating | IP65 |
| Width | 190mm |
| Mount Type | DIN Rail |
| Series | RS PRO |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -25°C |
| Switching Current | 25A |
| Terminal type | Wire |
| Handle Colour | Red |
| Number of Poles | 8 |
| Standards/Approvals | EN60947, RoHS |
| Switching AC Voltage | 690V ac |
| Switching Power | 11kW |
| Squirrel - cage motors | starting, switching off motors during running |
| RS PRO 8-Pole DIN Rail Isolator Switch -, IP65, 32A, 11 kWBrand | RS PRO |
Key Features
- Compact and easy to install DIN rail mounting switch.
- Rated IP65 for dust-tight and water protection.
- Red padlockable handle for secure operation.
- Suitable for switching currents up to 25A and power up to 11 kW.
- Made from flame retardant material with high short circuit capacity.
- Compatible with non-inductive and slightly inductive loads.
- Switching AC voltage rating up to 690V AC.
- Operating temperature range from -25°C to 80°C.
Product Description
RS PRO IP65 8-Pole DIN Rail Isolator Switch is a boxed isolator switch disconnector ideal for use in low voltage switchgear applications such as power distribution, load isolation, and motor controls. It supports 8 poles with a switching current of 25A and switching power of 11 kW, suitable for industrial and automation electrical systems.
Designed with a compact form factor for DIN rail mounting, this isolator switch features a robust red handle that is padlock compatible, ensuring safety and control. The device is rated IP65, providing full protection against dust ingress and water jets, making it suitable for harsh industrial environments.
Constructed from flame retardant materials, the isolator switch offers excellent switching capability and high short circuit capacity. It operates efficiently within a temperature range from -25°C up to 80°C, maintaining reliable performance under varied conditions.
This switch is compatible with a variety of electrical loads including non-inductive or slightly inductive loads, resistance furnaces, squirrel-cage motor controls, and other electromagnetic loads. It supports AC voltages up to 690V AC and meets industry standards EN60947 and RoHS compliance requirements.
Key technical details include dimensions of 280mm length, 190mm width, and 130mm depth, with wire terminal type for secure connections. This product does not include auxiliary contacts and is not certified for hazardous areas. It is part of the RS PRO series, known for quality and reliability trusted in electrical engineering solutions.
Compact DIN rail mount design with red padlockable handle. IP65 rated enclosure for dust-tight and water resistance. Switching current of 25A with power rating of 11 kW. Operates between -25°C and 80°C ambient temperatures.
Suitable for various inductive and resistive loads. Conforms to EN60947 and RoHS standards ensuring quality and safety.
Ideal for industrial automation, electrical distribution, HVAC systems, and manufacturing facility controls, this RS PRO Isolator Switch assures safe and effective load isolation. Explore more RS PRO electrical components and switches at EnvMart for comprehensive industrial electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current of this isolator switch is 25A.
It has a power rating of 11 kW.
The switch is rated IP65, providing protection against dust ingress and water jets.
It operates efficiently within a temperature range from -25°C to 80°C.
This model is compatible with non-inductive and slightly inductive loads, including resistance furnaces and squirrel-cage motor controls.
The dimensions are 280mm in length, 190mm in width, and 130mm in depth.
It is designed for DIN rail mounting.
The maximum AC voltage rating is 690V.
No, this product does not include auxiliary contacts.
It complies with EN60947 and RoHS standards.
The handle color of this switch is red and it is padlock compatible for secure operation.
The country of origin for this product is India.
