onsemi 3-Pin Surface Mount Positive Voltage Regulator MC78M05BDTG 35V 3.2mA Quiescent Current 125°C MC78M05BDTG

Free Delivery in India | Lowest Global Shipping Charges

onsemi 3-Pin Surface Mount Positive Voltage Regulator MC78M05BDTG 35V 3.2mA Quiescent Current 125°C MC78M05BDTG

Name: onsemi 3-Pin Surface Mount Positive Voltage Regulator MC78M05BDTG 35V 3.2mA Quiescent Current 125°C MC78M05BDTG
Brand: onsemi
SKU: 138682



Category Voltage Regulator IC Brand onsemi Condition New

Specifications

Country of Origin	India
Voltage	Regulators onsemi MC78M05BDTG, Voltage Regulator 35V 3-Pin RS Stock No
Brand	onsemi
Height	2.38mm
Length	6.73mm
Model	MC78M05BDTG
Width	6.22mm
Mount Type	Surface
Series	MC78Mxx
Maximum Operating Temperature	125°C
Polarity	Positive
Maximum Input Voltage	35V
Quiescent Current	3.2mA
Minimum Input Voltage	7V
Pin Count	3
Automotive Standard	AEC-Q100

Key Features

Operates with a minimum input voltage of 7V and a maximum input voltage of 35V.
Features low quiescent current of 3.2mA for efficient power use.
Compact 3-pin package with dimensions 6.73mm length, 6.22mm width, and 2.38mm height.
Incorporates internal current limiting, thermal shutdown, and output transistor protection for reliable operation.
Offers maximum operating temperature rating of 125°C suitable for demanding environments.
Meets automotive standard AEC-Q100 ensuring high reliability for automotive applications.
Designed for surface mount installation, facilitating automated PCB assembly.
Compatible with a range of applications including local on-card voltage regulation.

Product Description

onsemi MC78M05BDTG is a 3-pin surface mount linear voltage regulator designed for positive polarity applications. It provides stable voltage regulation with an input voltage range from 7V to 35V and an output voltage of 5V. The device incorporates internal current limiting, thermal shutdown, and output transistor safe operating area protection, ensuring reliable and robust performance under varying load conditions.

This voltage regulator is well-suited for applications requiring local, on-card voltage regulation such as industrial electronics, automotive systems, power management circuits, and consumer electronics. The compact footprint (length 6.73mm, width 6.22mm, height 2.38mm) allows for efficient PCB space utilization in high-density designs.

With a low quiescent current of 3.2mA and a maximum operating temperature rated at 125°C, the MC78M05BDTG supports energy-efficient operation in demanding thermal environments. The product complies with the automotive standard AEC-Q100, ensuring suitability for automotive electronic components.

Its surface mount package facilitates automated production processes, enhancing manufacturing efficiency. The regulator supports output currents up to 500mA when used with a suitable heat sink, making it versatile for a wide variety of power regulation needs.

Operates with input voltages from 7V to 35V. 3-pin surface mount positive voltage regulator. Low quiescent current of 3.2mA for power efficiency. Internal current limiting and thermal shutdown for device protection. Maximum operating temperature up to 125°C.

Compliant with AEC-Q100 automotive standard. Compact dimensions: 6.73mm length × 6.22mm width × 2.38mm height. Supports output current up to 500mA with heat sink.

This onsemi MC78M05BDTG voltage regulator is ideal for industrial, automotive, electronic manufacturing, and power management applications. Explore more voltage regulators and power management ICs in EnvMart’s extensive electronics component catalog.

Explore more products in our Voltage Regulator IC category.
