TRACOPOWER 3W SIP-8 Through Hole DC/DC Converter, 5V 600mA Output, 9 - 18V Input, 85°C Max Temp, Model TMR 3-1211
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER TMR 3 DC/DC Converter, 5V dc/ 600 mA, 1 |
| Brand | TRACOPOWER |
| Efficiency | 81% |
| Length | 21.8mm |
| Model | TMR 3-1211 |
| Depth | 11.1mm |
| Width | 9.2mm |
| Mount Type | Through Hole |
| Series | TMR 3 |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-8 |
| Minimum Operating Temperature | -40°C |
| MTBF | 4870000h |
| Number of outputs | 1 |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 18V dc |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 9V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 600mA |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Wide 2 | 1 input voltage range |
Key Features
- Supports continuous short circuit protection for enhanced reliability.
- Provides 1.5kV DC isolation voltage ensuring electrical safety.
- Operates within a wide temperature range from -40°C to +85°C.
- High efficiency of 81% enables low power loss during operation.
- Designed for industrial and instrumentation applications requiring compact DC voltage conversion.
- Equipped with 7 pins and a SIP-8 form factor for easy PCB mounting.
- Manufactured with UL94V-0 rated material to meet stringent safety standards.
- Ideal for communication equipment, industrial electronics, and instrumentation systems.
Product Description
TRACOPOWER TMR 3-1211 is a compact 3W DC/DC converter in a SIP-8 through-hole package delivering a regulated and isolated 5V output at 600mA with a wide input voltage tolerance from 9V to 18V DC. This converter provides high efficiency at 81%, making it suitable for applications demanding reliable power conversion with minimal heat dissipation.
Its robust design includes 1.5kV isolation voltage and continuous short circuit protection to ensure safety and durability in industrial environments. The converter operates efficiently within temperatures ranging from -40°C to +85°C, suitable for harsh conditions.
The TMR 3 series converters are designed specifically for communication equipment, industrial instrumentation, and other electronics where compact size and dependable DC voltage regulation are required. The unit features a 7-pin SIP-8 package with UL94V-0 flame retardant material, conforming to IEC/EN 60950-1 and UL 60950-1 safety standards.
This product's wide 2:1 input voltage range accommodates varying supply voltages, enhancing versatility in diverse systems. It supports remote on/off control and ensures stable output voltage with a narrow adjustment range of ±1%. With a mean time between failures (MTBF) of approximately 4,870,000 hours, the TMR 3-1211 guarantees long service life under demanding operating conditions.
Its compact dimensions (21.8mm×9.2mm×11.1mm) facilitate integration into space-constrained designs. Manufactured in Taiwan, the converter carries RoHS compliance, underscoring environmental responsibility.
Features a 2:1 input voltage ratio suitable for varied DC sources. Supports continuous short circuit protection for enhanced reliability. Provides 1.5kV DC isolation voltage ensuring electrical safety. Operates within a wide temperature range from -40°C to +85°C.
High efficiency of 81% enables low power loss during operation. Designed for industrial and instrumentation applications requiring compact DC voltage conversion. Equipped with 7 pins and a SIP-8 form factor for easy PCB mounting.
Manufactured with UL94V-0 rated material to meet stringent safety standards. Ideal for communication equipment, industrial electronics, and instrumentation systems. Meets RoHS compliance and IEC/EN 60950-1, UL 60950-1 standards.
Explore the EnvMart catalog for more TRACOPOWER DC/DC converters and power supply solutions engineered for industrial and commercial applications.
Explore more products in our DC-DC Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TMR 3-1211 operates within a wide input voltage range of 9V to 18V DC.
It can operate at a maximum temperature of 85°C.
This model has an efficiency rating of 81%, which helps minimize power loss during operation.
It is designed for through-hole mounting with a SIP-8 package type.
It features continuous short circuit protection and provides 1.5kV DC isolation voltage for enhanced safety.
The dimensions of the TMR 3-1211 are 21.8mm in length, 9.2mm in width, and 11.1mm in depth.
Yes, it meets RoHS compliance and conforms to IEC/EN 60950-1 and UL 60950-1 safety standards.
This converter is designed for industrial and instrumentation applications, including communication equipment and industrial electronics.
It supports a 2:1 input voltage ratio, accommodating varying supply voltages.
This model is manufactured in Taiwan.
