Eaton PKNM Series Residual Current Device 10A 2-Pole 30mA Type B 10kA 230V AC 236067 PKNM-10/1N/B/003-MW

Free Delivery in India | Lowest Global Shipping Charges

Eaton PKNM Series Residual Current Device 10A 2-Pole 30mA Type B 10kA 230V AC 236067 PKNM-10/1N/B/003-MW

Name: Eaton PKNM Series Residual Current Device 10A 2-Pole 30mA Type B 10kA 230V AC 236067 PKNM-10/1N/B/003-MW
Brand: Eaton
SKU: 136839
Price: 208.77 USD
Availability: InStock



Category Residual Current Device Brand Eaton Condition New

Specifications

Country of Origin	Romania
Range	PKNM
Brand	Eaton
Height	80mm
Model	236067 PKNM-10/1N/B/003-MW
Depth	70.5mm
Width	70mm
Mount Type	DIN Rail
Current Rating	10A
Series	PKNM
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	2
Standards/Approvals	IEC/EN 61008
Rated AC Voltage	230V ac
Tripping Characteristics	Type B
Tripping Mechanism	Electromagnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Break Time	Instantaneous

Key Features

Equipped with 30mA trip sensitivity ensuring user safety from electric shocks.
Type B tripping characteristics compatible with AC, pulsating DC and smooth DC residual currents.
10kA breaking capacity tailored for industrial electrical circuit protection.
Mounts easily on DIN rail with screw terminal type for secure connections.
Features a toggle switch reset actuator with instantaneous break time.
Incorporates electromagnetic tripping mechanism for rapid fault response.
Includes red and green contact position indicators for clear device status monitoring.
Designed and manufactured in Romania, compliant with IEC/EN 61008 standards.

Product Description

Eaton 236067 PKNM-10/1N/B/003-MW Residual Current Device (RCD) delivers precise electrical safety solutions with a current rating of 10A and a 2-pole configuration for effective fault detection. Operating at 230V AC, this device features a trip sensitivity of 30mA with Type B tripping characteristics, designed to detect all forms of residual current including AC, pulsating DC, and smooth DC currents.

This Eaton PKNM series RCD is engineered for industrial environments requiring reliable protection against electric shocks and electrical faults. The device swiftly interrupts power by using an electromagnetic tripping mechanism with instantaneous break times, enhancing workplace safety.

The product mounts securely on DIN rails and is equipped with screw-type terminals for robust electrical connections. Compact dimensions (80mm height, 70mm width, 70.5mm depth) ensure it fits effectively within standard switchboards and control panels.

Additional design features include a toggle switch reset actuator and built-in red/green contact position indicators that clearly display operational status. The device carries a breaking capacity of 10kA, allowing it to handle high fault currents typical in industrial electrical setups.

Constructed in Romania and compliant with IEC/EN 61008 standards, this RCD is part of Eaton's PKNM range, formerly known under Moeller, known for professional-grade electrical safety products. It is suitable for industrial, manufacturing, water treatment, and commercial electrical installations requiring sensitive and reliable residual current protection.

30mA trip sensitivity protects personnel from electric shock. Type B tripping offers comprehensive residual current detection. Electromagnetic instantaneous tripping mechanism for fast fault clearance. 10kA breaking capacity ensures safe interruption of high fault currents.

Compact DIN rail mount design facilitates installation in control panels. Screw terminal provides durable and stable cable connections. Red/green contact indicator provides clear status visibility. Toggle switch reset actuator for easy manual reset.

Complies with IEC/EN 61008 standards for electrical safety. Made in Romania assuring high manufacturing standards. Explore Eaton's full range of reliable circuit protection devices at EnvMart to enhance electrical safety and system reliability.
