Eaton PFIM Series Residual Current Device 25A 4-Pole 300mA Type A 10kA Instantaneous Trip 230V/400V 235437 PFIM-25/4/03-A-MW

Eaton 235437 PFIM-25/4/03-A-MW Residual Current Device is a compact and professional-grade device from the PFIM series designed for industrial electrical safety and fault current detection. Providing a 25A current rating with a 4-pole configuration, this device ensures critical protection by detecting residual currents with a trip sensitivity of 300mA and type A tripping characteristics, suitable for detecting AC and pulsating DC residual currents.

The device features an instantaneous electromagnetic tripping mechanism that guarantees immediate disconnection in case of fault, enhancing electrical equipment protection and personnel safety. Its construction allows for mounting on DIN rails and uses screw terminal connections for secure and reliable wiring.

With a breaking capacity of 10kA, the PFIM residual current device can withstand high short-circuit currents, making it ideal for demanding industrial environments. The toggle switch reset actuator provides a straightforward manual reset operation after fault clearance.

Meeting IEC/EN 61008 standards, it supports rated AC voltages of 230V and 400V, addressing a wide range of electrical distribution applications. The device's compact dimensions of 80mm height, 65.5mm width, and 70.5mm depth allow efficient space utilization in control panels.

This Eaton device, manufactured in Romania, is ideally suited for use in electrical automation, industrial control systems, and commercial installations requiring reliable residual current protection to prevent electric shocks and fire hazards.

Designed for industrial fault and residual current protection. Features instantaneous electromagnetic tripping mechanism. Mounts easily on DIN rail with screw terminals. Breaking capacity rated at 10kA ensures robust safety margin.

Compact dimensions of 80mm height, 65.5mm width, and 70.5mm depth. Reset actuator is a toggle switch for quick manual reset. Complies with IEC/EN 61008 standards. Suitable for 230V and 400V AC rated voltages. Engineered for professional electrical installations and automation.
